Charles McMurray Co. 2021 Catalog

1367 / 1590

7/8" dia.
wheel
7/8" dia.
wheels
JH2200F Series Sliding Bypass Door Hardware
Aluminum Fascia Track
• Top hung hardware for 1-3/8" thick doors
• Aluminum single extrusion twin rail fascia track can be cut-down to
accommodate narrower doors
• Adjustable side-mount hanger plates allow for precision door alignment
• Residential grade
50 lb. Set Includes 75 lb. Set Includes
4 ea hanger w/screws 4 ea hanger w/screws
1 ea guide w/screws 1 ea guide w/screws
7 ea 1-1/4" track screws 7 ea 1-1/4" track screws
Item No. For Doors Finished Openings
Height Width
2 - 2'0" (48") Door Ht +1-3/4" 47"
2 - 2'6" (60") Door Ht +1-3/4" 59"
2 - 3'0" (72") Door Ht +1-3/4" 71"
Packaged Sets - Includes track & 50lb. hdwe set
Item No. Size Box List Set
List Set
Full Box
48" 5 sts $53.36 $46.82
60" 5 sts $64.12 $56.10
72" 5 sts $71.90 $63.10
Components/Accessories
Item No. Description Box List Ea.
List Ea.
Full Box
Door Guide Adj. 100 $2.76 $2.20
Door Guide 1-3/8" 100 $1.88 $1.58
Door Stop 50 $4.18 $2.92
Track Stop 100 $7.62 $5.34
Door Hanger 75 lb. 50 $5.66 $4.50
Door Hanger 50 lb. 100 $2.28 $1.90
White Nylon Guide
for 1-3/8" Doors (White)
50 Lb. Hanger
(3/8" offset)
75 Lb. Hanger
(3/8" offset)
Adjustable Door Guide
3/4" or 1-3/8" Doors (Brown)
Track Stop
Door Stop
1-1/8"
2-27/32"
1-5/8"
Bulk Pack - Track & hardware sold separately
Track
Item No. Length Box List Ea.
List Ea.
Full Box
48" 25 $31.92 $26.40
60" 25 $37.48 $31.24
72" 25 $44.62 $37.18
96" 10 $62.70 $51.84
120" 10 $82.00 $67.80
Hardware Sets
Item No. Description Box List Set
List Set
Full Box
For 50 lb. doors 50 $10.68 $9.08
For 75 lb. doors 50 $17.22 $14.64
NOTES:
For sliding/bypass components & accessories see pages 1368-1375.
For flush pulls see pages 1316.
Installation instructions are available at
under the Resources tab.
Maximum Weight with JH2238 hangers: 50 lbs. per door
Maximum Weight with JH2228 hangers: 75 lbs. per door
Door Thickness: 1-3/8"
2-Door Set Includes
1 ea JH2200F track
4 ea JH2238 hangers
1 ea JH2135 door guide
2 ea JH15US15 satin nickel flush pull 7/8" dia.
1 st Hardware mounting screws
7/8" Nickel
Flush Pull
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 2021 1946 1367 Prices subject to change without notice.
