JH138F Series Sliding/Bypass Door Hardware
Aluminum Fascia Track
JH30US15
2-1/8"
Nickel Pull
2-Door Packaged Sets - Includes hardware & track
Item No. Length
# of
Doors Box List Set
List Set
Full Box
48" 2 5 $112.14 $95.32
60" 2 5 $124.94 $106.20
72" 2 5 $135.30 $115.34
96" 4 3 $221.16 $188.00
*Includes 2 hardware sets and 2 stops
Adjustable Bypass
Door Guide (brown)
Bulk Pack - Track & hardware sold separately
Track
Item No. Length Box List Ea.
List Ea.
Full Box
Mill Finish
60" 10 $63.70 $54.14
72" 10 $74.32 $63.36
96" 5 $102.96 $87.52
120" 5 $134.46 $113.96
144" 5 $156.50 $133.02
192" 5 $215.44 $182.58
Bronze Finish
60" 10 $112.18 $95.06
72" 10 $129.00 $109.32
96" 5 $177.16 $150.14
144" 5 $282.38 $238.56
* Must ship LTL
2-Door Hardware Sets
Item No. Description Box List Set
List Set
Full Box
For 125 lb. doors 25 $44.64 $37.94
For 200 lb. doors 25 $85.64 $71.88
Components
125 lb. Set Includes 200 lb. Set Includes
2 pr JH1120 hangers 2 pr JH1125 hangers
2 ea JH30US15 2-1/8" flush pull 2 ea JH30US15 2-1/8" flush pull
1 ea JH2135 door guide 1 ea JH2135 door guide
1 ea JH2155 door stop 1 ea JH2155 door stop
1 ea wrench 1 ea wrench
Mounting screws Mounting screws
min 1-3/4"max 2-1/4"
3/8"
2-3/16"
door height +2-3/8"
3-7/16"
2-3/16"
Maximum Weight with JH1120 hangers: 125 lbs. per door
Maximum Weight with JH1125 hangers: 200 lbs. per door
Door Thickness: 1-3/8"
NOTES:
For sliding/bypass components & accessories see pages 1368-1375.
For soft-close hardware see page 1354.
For flush pulls see pages 1316.
Installation instructions and videos are available at
under the Resources tab.
• Aluminum single extruded twin box rail fascia track can be cut down to accommodate
narrower doors; mill or bronze finish
• Convex rails provide one-point contact for wheels to ride on;
dirt traps on both sides allow hanger wheel to be dust-free
• Tricycle hanger design gives even weight distribution to track
rails; will not bind
• Commercial grade top hung sliding door hardware
2-Door Packaged Sets Include
1 ea Track 1 ea JH2155 door stop
4 ea JH1120 hangers 2 ea JH30US15 2-1/8" flush pull
1 ea JH2135 door guide 1 ea JH1712 wrench
Mounting screws
Item No. Description Box List Ea.
Hanger f/125 lb. (pair) 50 pr
Hanger f/200 lb. (bulk) 50 ea $16.22
Hanger f/200 lb. (pair) 50 pr $31.98
Wrench 100 ea $1.10
Door Guide 100 ea $2.20
Door Stop 50 ea $2.92
200 lb. Hanger - Ball-Bearing
JH1120PLB2
125 lb. Hanger
Wheel: 1" dia.
Plate: 3/4"x2-1/4"
Wheel: 1" dia.
Plate: 3/4"x2-1/4"
Door Stop Wrench
*LTL ONLY
item on
this page
Option Available
