Charles McMurray Co. 2021 Catalog

1366 / 1590

JH2200 Series Sliding Bypass Door Hardware
Components/Accessories
Bulk Pack - Track & hardware sold separately
Track
Item No. Length Box List Ea.
List Ea.
Full Box
60" 10 $26.32 $21.68
72" 10 $31.30 $25.78
96" 10 $41.76 $34.38
120" 10 $56.82 $46.80
144" 10 $65.28 $53.98
Hardware
Item No. Description Box List Ea.
List Ea.
Full Box
Door Guide Adjust. 100 $5.52 $2.20
Door Guide 1-3/8" 100 $1.88 $1.58
Door Stop 50 $4.18 $2.92
Door Hanger 50 lb. 100 $2.86 $2.28
Door Hanger 50 lb. 100 $2.28 $1.90
Door Hanger 75 lb. 50 $5.60 $4.46
Door Hanger 75 lb. 50 $5.66 $4.50
Item No. For Doors Finished Openings
Height Width
Two 2'6" (59") Door Ht. +1-3/4" 59"
Two 3'0" (71") Door Ht. +1-3/4" 71"
Three 2'8" (94") Door Ht. +1-3/4" 94"
Four 2'0" (94") Door Ht. +1-3/4" 94"
NOTE:Track is 1" under the nominal length except for 96"
opening which is 94" long.
Nylon Door Guide for
1-3/8" Doors (white)
50 lb. Hanger
(3/8" offset)
Adjustable Door Guide
3/4" or 1-3/8" Doors (brown)
50 lb. Hanger
(1/16" offset)
Door Stop
for 3/4" Door
Packaged Sets - Includes track & hardware
Item No. Length
# of
Doors Box List Set
List Set
Full Box
60" 2 5 $51.92 $45.14
72" 2 5 $58.48 $50.86
96" 4 5 $103.24 $89.78
7/8" Nickel Flush Pull
75 lb. Hanger
(3/8" offset)
75 lb. Hanger
(1/16" offset)
Track Stop
2-Door Set includes
1 ea Track length
2 ea hangers 1/16" offset 1 ea door guide
2 ea hangers 3/8" offset 2 ea 7/8" nickel flush pulls
1 st Hardware mounting screws
4-Door Set includes
1 ea Track length
4 ea hangers 1/16" offset 2 ea door guides
4 ea hangers 3/8" offset 4 ea 7/8" nickel flush pulls
2 ea track stops 2 ea door stops
1 st Hardware mounting screws
7/8" dia. wheel
1-3/8" doors
7/8"
3/8"
2216
2238
door height +1-3/4"
Picture shows application for
1-3/8" doors. For 3/4" doors,
mount track directly behind
finish trim.
7/8" dia. wheel
NOTES:
For sliding/bypass components & accessories see pages 1368-1375.
For flush pulls see pages 1316.
Installation instructions are available at
under the Resources tab.
Maximum Weight with JH2216/JH2238 hangers: 50 lbs. per door
Maximum Weight with JH2226/JH2228 hangers: 75 lbs. per door
Door Thickness: 3/4" or 1-3/8"
• Top hung hardware for 3/4" or 1-3/8" thick doors
• Aluminum single extrusion twin rail track can be cut
down to accommodate narrower doors
• Adjustable side-mount hanger plates allow for precision
door alignment
• Residential grade
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 2021 1946 1366 Prices subject to change without notice.
