Charles McMurray Co. 2021 Catalog

1362 / 1590

JH134F Series Sliding/Bypass Door Hardware
Aluminum Fascia Track
*LTL ONLY
item on
this page
Door Stop
Bulk Pack - Track & hardware sold separately
Track
Item No. Length Box List Ea.
List Ea.
Full Box
60" 10 $71.10 $60.44
72" 10 $84.68 $71.98
96" 5 $114.98 $97.74
120" 5 $149.80 $126.94
144" 10 $178.14 $150.96
192" 5 $240.74 $204.02
* Must ship LTL
2-Door Hardware Sets
Item No. Description Box List Set
List Set
Full Box
For 125 lb. doors 25 $46.46 $39.38
For 200 lb. doors 25 $85.56 $80.42
JH30US15
2-1/8" Nickel Pull
Adjustable Bypass
Door Guide (brown)
Components
NOTES:
For sliding/bypass components & accessories see pages 1368-1375.
For soft-close hardware see page 1354.
For flush pulls see pages 1316.
Installation instructions and videos are available at
under the Resources tab.
Maximum Weight with JH1120 hangers: 125 lbs. per door
Maximum Weight with JH1125 hangers: 200 lbs. per door
Door Thickness: 1-3/4"
• Aluminum single extruded twin box rail fascia track can
be cut-down to accommodate narrower doors; mill finish
• Convex rails provide one-point contact for wheels to ride
on; dirt traps on both sides allow hanger wheel to be
dust-free
• Tricycle hanger design gives even weight distribution
to track rails; will not bind
• Commercial grade top hung sliding door hardware
Wrench
200 lb. Hanger - Ball-Bearing
Item No. Description Box List Ea.
Hanger f/125 lb. (pair) 50 pr
Hanger f/200 lb. (bulk) 50 ea $16.22
Hanger f/200 lb. (pair) 50 pr $31.98
Wrench 100 ea $1.10
Door Guide 25 ea $4.38
Door Stop 50 ea $2.92
125 lb. Set Includes 200 lb. Set Includes
2 pr JH1120 hangers 2 pr JH1125 hangers
2 ea JH30US15 2-1/8" flush pull 2 ea JH30US15 2-1/8" flush pull
1 ea JH2134 door guide 1 ea JH2134 door guide
1 ea JH2155 door stop 1 ea JH2155 door stop
1 ea wrench 1 ea wrench
Mounting screws Mounting screws
JH1120PLB2
125 lb. Hanger
Wheel: 1" dia.
Plate: 3/4"x2-1/4"
Wheel: 1" dia.
Plate: 3/4"x2-1/4"
min 1-3/4"max 2-1/4"
3/8"
2-3/16"
door height +2-3/8"
2-3/16"
4" Option Available
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 2021 1946 1362 Prices subject to change without notice.
