JH200 Series Sliding/Bypass Door Hardware
*LTL ONLY
item on
this page
JH2031
Single Post Heavy-Duty
Door Guide
1-7/8"
1-19/64"
7/8"
Bulk Pack - Track & hardware sold separately
Track
Item No. Length Box List Ea.
List Ea.
Full Box
72" 5 $76.10 $64.68
96" 5 $100.10 $85.10
120" 5 $132.60 $112.02
144" 5 $150.22 $127.68
192" 5 $198.78 $168.96
* Must ship LTL
Hardware
Item No. Description Box List Ea.
List Ea.
Full Box
Hanger 400 lb. (pair) 25 $85.24 $71.54
Hanger-Side Mount 1-3/8" 50 $55.86 $45.60
Hanger-Side Mount 1-3/4" 50 $55.86 $45.60
Single Post Guide 25 $6.14 $5.02
Single Post Guide HD 25 $6.44 $5.26
Track Stop 25 $10.14 $8.58
Multi-Door Pull Catches
For use with 2 or more doors sliding
from one side. Zinc finish. Set includes
2 catches, wrench and screws. 1 set
per bag, 10 sets per box. Sold per set.
Item No. List Set
JH2054PLBG $13.84 use an edge pull
on lead door
Top View-
shown w/2 sets.
2/set
• Top-hung hardware system designed to carry heavy doors; allows doors to hang naturally
• Track can be cut-down to accommodate narrower doors
• Heavy-duty extruded aluminum I-beam track
• Four wheel ball bearing hangers with machine turned
1" wheels
• Heavy-duty door guides
• Commercial grade
Components Needed for 2, 3, 4-Door Applications
2-Door Set
48,60,72,96"
3-Door Set
72,96,144"
4-Door Set
96,120,144,192"
JH200 Track 2 ea 2 ea 2 ea
JH2020 Hanger 2 pr 3 pr 4 pr
JH2155 Door Stop 1 ea 1 ea 2 ea
JH2030 Floor Guide 2 ea 4 ea 4 ea
JH2031 Floor Guide 1 ea 2 ea 2 ea
JH2055 Track Stop --- 2 ea 2 ea
JH1712 Wrench --- 1 ea 1 ea
Flush Pulls 2-1/8" 2 ea 3 ea 4 ea
NOTES:
For sliding/bypass components & accessories see pages 1368-1375.
For flush pulls see pages 1316.
For edge pulls see page 180.
Installation instructions and videos are available at
under the Resources tab.
This track can also be used for:
Pocket Door............. page 1378
Wall Mount Door...... page 1355
Folding Door............ page 1392
Maximum Weight: 400 lbs. per door
For Doors 1-1/8" or thicker
2-SNAP IN PLA
Single Post
Door Guide
hanger
3"L x 2"H x 1-5/16"W
1" dia. wheels.
Track Stop
Hardware
hanger
Side mount f/1-3/8" doors.
1" dia. wheels.
hanger
Side mount f/1-3/4" doors.
1" dia. wheels.
Plate:
2-1/4" x 3/4"
Plate:
2-1/4" x 3/4"
Option Available
