Charles McMurray Co. 2023 Catalog

525 / 1645

Specifications
Wattage 4W/ft.
Lumens 216/ft.
Efficacy (lm/W) 54
Input Voltage 12VDC
Lamp Life 50,000 Hours
Max. Per 60W
Power Supply 15'
Max. Continuous Run 10'
Mounting Surface
Warranty 5 Year
Certifications
Beam Angle 120°
Optional Accessories
See pages 535-540 for LED accessories.
12V System-LED
Eurolinx Typical Setup
Power Supply
Mounting Block
(Included w/Power Supply)
Eurolinx Linear LED
Controller
(pg. 538-539 for options)
LIGHTING
800.533.0533 525 Prices subject to change without notice.
McMurray.com
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
Required Items:
Required Items
Light Fixtures
Item No. Length Watts List Ea.
Cool White (5000K)
43-3/4" 15W $218.76
Warm White (3000K)
7-3/4" 3W $113.52
19-3/4" 7W $146.46
31-3/4" 11W $182.60
43-3/4" 15W $218.76
Power Supply (transformers - choose one)
Item No. Description List Ea.
15W 12VDC Wall Mount* $58.86
60W 12VDC Dimmable* $152.88
60W 12VDC Dimmable** $240.22
NOTES: See page 535 for specifications.
*Dimmable on trailing edge (12V side), 6-port mounting block
and power cord included.
**Dimmable by standard LED wall dimmers, 6-port mounting
block included.
Eurolinx LED Linear Light System
Lighting Strips, 4W per foot
• Aluminum body with flat design, only 5/16"H
• Directional beam-spreads based on orientation
• Linkable (back-to-back or link cord) up to 10'
• 79" starter cord,mountingU-clips and back-to-back connector included
• Screw-onmounting clips included (optional magnetic U-clips for metal
surface mounting available by special order)
• Dimmable
Two Beam Spreads:
Powered Left Side
Powered Right Side
Linkable (back-to-back or link cord) up to 10' continuous run.
(Back-to-back link included.)
Screw-on mounting clips (2) included.
Length
03/23
03/23
