Required Items

Light Fixtures

Item No.

Finish

Bulb

List Ea.

POC3LEDSFRCBL

Black

Cool (5000K) $85.00

POC3LEDSFRCWH

White Cool (5000K) $85.00

POC3LEDSFRWBL

Black Warm (3000K) $85.00

POC3LEDSFRWNI

Nickel

Warm (3000K) $85.00

POC3LEDSFRWWH

White Warm (3000K) $85.00

Power Supply

(transformers - choose one)

Item No.

Description

List Ea.

L-DC-ELT15WP-CON

15W 12VDC Wall Mount* $58.86

L-DC-SLELT60-1

60W 12VDC Dimmable* $152.88

L-DCE60D-CON

60W 12VDC Dimmable** $240.22

NOTES: See page 535 for specifications.

*Dimmable on trailing edge (12V side), 6-port mounting block

and power cord included.

**Dimmable by standard LED wall dimmers, 6-port mounting

block included.

• Durable all-metal construction

• 120° beam spread

• Luniform output - no "dots"

• 79" starter cord, AMP® connector and surface

mount ring are included

• Dimmable

Specifications

Wattage

3W

Lumens

234

Efficacy (lm/W)

78

Input Voltage

12VDC

Lamp Life

50,000 Hours

Max. Per 60W

Power Supply

20 Fixtures

Max. Continuous Run N/A

Mounting

Recess/Surface

Warranty

5 Year

Certifications

Beam Angle

120°

Power Pockit® 3W LED Lights

Optional Accessories

See pages 535-540 for LED accessories.

Option 1

(To control each light individually)

:

Up to six Controllers plugged into (1) Mounting Block

Option 2

(To control all lights at the same time)

:

One Controller plugged in before the Mounting Block

2-1/2"

3/8"

thru-way for wire exit

Surface Mount

79"

2-1/4"

2-1/2"

1/4"

Recess Mount

12V System-LED

See pg. 1142 for hole saws

Power Pockit® 3W Typical Setup

Power Supply

Mounting Block

(Included w/Power Supply)

Power Pockit® 3W

Controller

(pg. 538-539 for options)

LIGHTING

800.533.0533

522
