Charles McMurray Co. 2023 Catalog

523 / 1645

EquiLine 3W LED Puck Lights
Economical LED puck features a slim profile and uniform light output.
• Recess or surface mount (surface mount ring available separately)
• 100° beam spread
• Luniform output - no "dots"
• 79" starter cord and AMP® connector are included
• Dimmable
Required Items
Light Fixtures
Item No. Finish Bulb List Ea.
Nickel Cool (5000K) $41.22
Nickel Warm (3000K) $41.22
Power Supply (transformers - choose one)
Item No. Description List Ea.
15W 12V DC Transformer* $58.86
60W 12VDC Dimmable* $152.88
60W 12VDC Dimmable** $240.22
NOTES: See page 535 for specifications.
*Dimmable on trailing edge (12V side), 6-port mounting block
and power cord included.
**Dimmable by standard LED wall dimmers, 6-port mounting
block included.
Surface Mount Ring
Item No. Finish List Ea.
Satin Nickel $3.94
Optional Accessories
See pages 535-540 for LED accessories.
Option 1 (To control each light individually):
Up to six Controllers plugged into (1) Mounting Block
Option 2 (To control all lights at the same time):
One Controller plugged in before the Mounting Block
Surface mount ring sold
separately.
Specifications
Wattage 3W
Lumens 218
Efficacy (lm/W) 73
Input Voltage 12VDC
Lamp Life 25,000 Hours
Max. Per 60W
Power Supply 20 Fixtures
Max. Continuous Run N/A
Mounting Recess/Surface
Warranty 2 Year
Certifications
Beam Angle 100°
12V System-LED
See pg. 1142 for hole saws
Equiline 3W Typical Setup
Power Supply
Mounting Block
(Included w/Power Supply)
Equiline 3W
Controller
(pg. 538-539 for options)
LIGHTING
800.533.0533 523 Prices subject to change without notice.
