Neoloop Typical Setup
Power Supply
Mounting Block
(Included w/Power Supply)
Top-Emitting Neoloop
L-N2-UCLP
L-N1-UCLP
Surface mount w/u-clips
Controller
(pg. 538-539 for options)
LIGHTING
800.533.0533
528
Prices subject to change without notice.
McMurray.com
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &
CLOSET
ORGANIZERS
KITCH./BATH
LIGHTING SLIDES
DOORS &
DRAWERS
LOCKS &
CATCHES
AVENTOS &
LIFTS
CABINET
HINGES
DECORATIVE
HARDWARE
• 3 Watts per foot Luniform output for continuous illumination, light temperature 3000K (warm) or 4800K (cool)
• 16.4' roll, cuttable every 1"
• Linkable with B2B connectors or linking cords, no soldering required
• 79" starter cords are molded on each end for easy installation
• Recess or surface mount with u-clips indoor, outdoor, damp and
wet locations, when used with factory-installed inputs
Required Items
Flexible Lighting
(16.4' Roll)
Item No.
Light Color List Ea. List Ea. 2
L-N1-12V3WM-30K-5M Warm 3000K $380.56 $322.52
L-N1-12V3WM-48K-5M Cool 4800K $380.56 $322.52
L-N2-12V3WM-30K-5M Warm 3000K $411.68 $348.88
L-N2-12V3WM-48K-5M Cool 4800K $411.68 $348.88
Power Supply
(transformers)
Item No.
Description
List Ea.
L-DC-ELT15WP-CON 15W 12VDC Wall Mount* $58.86
L-DC-SLELT60-1
60W 12VDC Dimmable* $152.88
Neoloop works with all Tresco 12VDC power supplies.
See pg. 535 for more options/specifications.
Neoloop LED Flexible Silicone Lighting System
Optional Items
Item No.
Description
List Ea.
List Ea.
10
Side-Emitting
L-N1-12PKT-2M 79" Starter Cord $36.42 $23.46
L-N1-LNK60
24" Link Cord
$59.54 $38.34
L-N1-LNK120
48" Link Cord
$63.26 $40.74
L-N1-BTB
BTB Connector
$17.82 $11.48
L-N1-ENDCAP
End Cap
$1.44 $1.16
Top-Emitting
L-N2-12PKT-2M 79" Starter Cord $35.36 $22.78
L-N2-LNK60
24" Link Cord
$59.28 $38.18
L-N2-LNK120
48" Link Cord
$63.26 $40.74
L-N2-BTB
BTB Connector
$21.26 $13.70
L-N2-ENDCAP
End Cap
$2.60 $2.06
See page 540 for specifications.
12V System-LED
Specifications
Side-Emitting Top-Emitting
Wattage
3W/ft.
3W/ft.
Lumens
100/ft.
200/ft.
Efficacy (lm/W)
33.3
66.7
Input Voltage
12VDC
12VDC
Diode Life
50,000 Hours 50,000 Hours
Bend Radius/Axis 4" Horizontal
4" Vertical
Max. Per 60W
Power Supply
20'
20'
Mounting
Recess/Surface Recess/Surface
Warranty
5 Year
5 Year
Certifications
Beam Angle
110°
145°
Top-Emitting
(200 Lumens/ft.)
Illuminates from a curved top
Bends on a vertical axis
Uses: Under counter accents,
soffits or toe kick lighting
Side-Emitting
(100 Lumens/ft.)
Illuminates from the side
Bends on a horizontal axis
Uses: Highlighting dark millwork,
outlining commercial logos & more
N1
N2
Recess mount
Dado:(16mm)5/8"Wx(12mm)15/32"D
U-clips are sold in packs of 10.
Item No.
List Ea.
Pk.
List Ea.
10 Pks.
L-N1-UCLP $22.60 $14.56
L-N2-UCLP $25.52 $16.44
L-N2-ENDCAP
L-N1-ENDCAP
Cuttable
every 1"
Tick marks on
mounting side of
light strip show
where to cut
