Runner setback when using all other locking devices
563 H/.
runner setback
563 F
runner setback
sub-front
thickness
13
(1/2")
17.5
(11/16")
20.5
(13/16")
23.5
(15/16")
sub-front
thickness
13
(1/2")
14.5
(9/16")
17.5
(11/16")
20.5
(13/16")
16
(5/8")
20.5
(13/16")
23.5
(15/16")
26.5
(1-1/32")
16
(5/8")
17.5
(11/16")
20.5
(13/16")
23.5
(15/16")
19
(3/4")
23.5
(15/16")
26.5
(1-1/32")
29.5
(1-5/32")
19
(3/4")
20.5
(13/16")
23.5
(15/16")
26.5
(1-1/32")
16
(5/8")
19
(3/4")
22
(7/8")
16
(5/8")
19
(3/4")
22
(7/8")
drawer front thickness
drawer front thickness
█
Setbacks in this table set the face of the drawer front flush with the face of the cabinet
█
If a depth adjustable locking device is needed, please see the locking device and table above
Calculating runner setback
563 H/. (sub-front thickness + drawer front thickness minus
11.5
(7/16") = runner setback)
563 F (sub-front thickness + drawer front thickness minus
14.5
(9/16") = runner setback)
NOTE:
For mounting hole position, add
7
(9/32") to runner setback
mounting hole position
runner setback
NOTE:
runner cannot be
mounted below opening
drawer front
drawer sub front
Installation
Inset Drawer Application for 563 Drawer Slides Specifications
Runner setback when using depth adjustable locking device
(T51.1901.PS)
563 H/.
runner setback
563 F
runner setback
sub-front
thickness
13
(1/2")
20
(25/32")
23
(29/32")
26
(1-1/32")
sub-front
thickness
13
(1/2")
17
(21/32")
20
(25/32")
23
(29/32")
16
(5/8")
23
(29/32")
26
(1-1/32")
29
(1-5/32")
16
(5/8")
20
(25/32")
23
(29/32")
26
(1-1/32")
19
(3/4")
26
(1-1/32")
29
(1-5/32")
32
(1-1/4")
19
(3/4")
23
(29/32")
26
(1-1/32")
29
(1-5/32")
16
(5/8")
19
(3/4")
22
(7/8")
16
(5/8")
19
(3/4")
22
(7/8")
drawer front thickness
drawer front thickness
█
Setbacks in this table recess the face of the drawer front inside of the cabinet 1 (1/32")
█
The depth adjustment can then be used to move the drawer front out to its desired position,
2.5 (3/32") out adjustment only
Calculating runner setback
563 H/. (sub-front thickness + drawer front thickness minus
9
(11/32") = runner setback)
563 F (sub-front thickness + drawer front thickness minus
12
(15/32") = runner setback)
NOTE:
For mounting hole position, add
7
(9/32") to runner setback
Setback information
NOTE:
For mounting hole position add 7 (9/32") to runner setback
