MOVENTO is the latest advancement in concealed runner technology.
TIP-ON BLUMOTION for MOVENTO combines the advantages of both TIP-ON
and BLUMOTION, for wood drawers. This combination ensures that drawers
open with just a light touch, have a smooth running action, and a silent and
effortless closing action.
• Designed for 1/2" to 5/8" material
• Designed for use with TIP-ON BLUMOTION or SERVO-DRIVE
touch-to-open system
• 4-dimensional tool-free adjustment
Rear notching
Drawers must be notched in the back to
accommodate MOVENTO runners.
Make the back panel shorter and extend the
drawer bottom to the back of the drawer.
Option - no notching
Dimensions
The notches must be flush with the drawer
sides and bottom.
rear
view
General Specifications
Complete Runner System
• Full Extension concealed runners with BLUMOTION soft-close
• Bottom mount holes on 763 standard duty
• Zinc-coated steel
• Elongated holes for depth adjustment
• Available in standard and heavy duty
• Lateral stabilizer for wide applications
Locking Devices
• Stamped steel base with synthetic, spring-loaded release levers
• Captive right device, self-aligning left device
• Self-adjusting drawer length tolerance
• Tool-free front side-to-side adjustment
• Available for narrow drawers
One Runner for All Applications
MOVENTO runners are designed for the American 3" increment cabinet depth system.
Installation is possible in frameless or blocked-out face frame cabinets.
Load Capacities
• 125 lbs. static for MOVENTO 763 standard duty series
• 170 lbs. static for MOVENTO 769 heavy duty series
MOVENTO 763/769 Series For Wood Drawers
Drawer Components
NOTE:
For 763 and 769 series, rear brackets and sockets
cannot be used. Cabinet sides must be blocked-out flush with
the inside of the face frame.
runners
locking devices
