JH200 Series Sliding/Bypass Door Hardware

JH2031

Single Post Heavy-Duty

Door Guide

1-7/8"

1-19/64"

7/8"

Bulk Pack - Track & hardware sold separately

Track

Item No.

Length

Box List Ea.

List Ea.

Full Box

JH200-72

72"

5

$76.10 $64.68

JH200-96

96"

5

$100.10 $85.10

JH200-120

120"

5

$132.60 $112.02

JH200-144

144"

5

$150.22 $127.68

JH200-192 *

192"

5

$198.78 $168.96

* Must ship LTL

Hardware

Item No.

Description Box List Ea.

List Ea.

Full Box

JH2020PLB2

Hanger 400 lb. (pair)

25 $85.24 $71.54

JH2022

Hanger-Side Mount 1-3/8" 50 $55.86 $45.60

JH2023

Hanger-Side Mount 1-3/4" 50 $55.86 $45.60

JH2030

Single Post Guide

25 $6.14 $5.02

JH2031

Single Post Guide HD 25 $6.44 $5.26

JH2055

Track Stop

25 $10.14 $8.58

Multi-Door Pull Catches

For use with 2 or more doors sliding

from one side. Zinc finish. Set includes

2 catches, wrench and screws. 1 set

per bag, 10 sets per box. Sold per set.

Set No.

List Set

JH2054PLBG $13.84

use an edge pull

on lead door

Top View-

shown w/2 sets.

2/set

Components Needed for 2, 3, 4-Door Applications

2-Door Set

48,60,72,96"

3-Door Set

72,96,144"

4-Door Set

96,120,144,192"

JH200 Track

2 ea

2 ea

2 ea

JH2020 Hanger

2 pr

3 pr

4 pr

JH2155 Door Stop

1 ea

1 ea

2 ea

JH2030 Floor Guide

2 ea

4 ea

4 ea

JH2031 Floor Guide

1 ea

2 ea

2 ea

JH2055 Track Stop

---

2 ea

2 ea

JH1712 Wrench

---

1 ea

1 ea

Flush Pulls 2-1/8"

2 ea

3 ea

4 ea

NOTES:

For sliding/bypass components & accessories see pages 1382-1389.

For flush pulls see pages 1328.

For edge pulls see page 1273.

For soft-close hardware see page 1368a.

Installation instructions and videos are available at

www.johnsonhardware.com

under the Resources tab.

This track can also be used for:

Pocket Doors............ page 1392

Wall Mount Door...... page 1369

Folding Doors........... page 1406

Maximum Weight: 400 lbs. per door

For Doors 1-1/8" or thicker

2-SNAP IN PLA

JH2030

Single Post

Door Guide

JH2020PLB2

hanger

3-1/2"L x 2"H x 1-5/16"W

1" dia. wheels

JH2055

Track Stop

Hardware

JH2022

hanger

Side mount f/1-3/8" doors

1" dia. wheels

JH2023

hanger

Side mount f/1-3/4" doors

1" dia. wheels

Plate:

2-1/4" x 3/4"

Plate:

2-1/4" x 3/4"

• Top-hung hardware system designed to carry heavy doors; allows doors to hang naturally

• Track can be cut-down to accommodate narrower doors

• Heavy-duty extruded aluminum I-beam track

• Four wheel ball bearing hangers with machine turned

1" wheels

• Heavy-duty door guides

• Commercial grade

01/23

*

DOOR

HARDWARE

TOOLS FASTENERS SHOP &

FINISHING

ABRASIVES LACQUERS &

FINISHES

ADHESIVES FURNITURE

HARDWARE

EDGING &

DECOR.WOOD

SHELF &

CLOSET

ORGANIZERS

KITCH./BATH

LIGHTING SLIDES

DOORS &

DRAWERS

LOCKS &

CATCHES

AVENTOS &

LIFTS

CABINET

HINGES

DECORATIVE

HARDWARE

DOOR LOCKS & HARDWARE

800.533.0533

1378

Prices subject to change without notice.

McMurray.com

JH2066

Option Available
