Charles McMurray Co. 2023 Catalog

1375 / 1645

11 Sliding/Bypass Door Hardware
Maximum Weight: 150 lbs. per door
Minimum Door Thickness: 3/4"
Hardware
Item No. Description Box List
Guide-centered (white) 100 ea $1.38
Guide-offset (white) 100 ea $1.04
Soft-close Hardware 25 ea $83.58
Hanger, Ball-Bearing (pair) 50 pr $30.32
Adjustment Wrench 100 ea $1.10
Multi-Door Pull Catch (2/st) 10 st $13.84
Door Stop 50 ea $2.92
Components
JH11
Offset Guide
JH10
Centered Guide
JH2054PLBG
Multi-Door Pull Catch
Up to 150 lb.
JH2155
Door Stop
JH2031
Single Post Heavy-Duty
Door Guide (Zinc w/White)
JH2030
Single Post Door Guide
(Zinc w/White)
Plate:
2-1/4" x 3/4"
Plate:
2-1/4" x 3/4"
• Precision extruded aluminum jump-proof box rail track
• Height adjustable ball-bearing door hanger with
quick- release clip
• Commercial grade top-hung hardware
Components Needed for 2-Door, 4-Door
2-Door 4-Door
JH111 track 2 ea 2 ea
JH1025 Hanger 2 pr 4 pr
JH11 offset door guide 2 ea 4 ea
JH10 centered door guide 1 ea 2 ea
JH2155 door stop 1 ea 2 ea
JH1712 adjustment wrench 1 ea 1 ea
Flush pulls 2 ea 4 ea
Wrench
Bulk Pack - Track & hardware sold separately
Track
Item No. Length Box List Ea.
60" 25 $19.78
72" 25 $23.46
96" 25 $30.64
120" 10 $54.14
144" 10 $66.12
192" 10 $84.46
* Must ship LTL
.902"(23mm)
1.21" (31mm)
1-9/16"
(40mm) to
1-7/8"
(48mm)
Wheel: 3/4" dia.
Plate: 3/4"x2-1/4"
NOTES:
For sliding/bypass components & accessories see pages 1382-1389.
For flush pulls see pages 1328.
For soft-close hardware see page 1368b.
Installation instructions are available at
under the Resources tab.
This track can also be used for:
Pocket Doors............ page 1392
Folding Doors........... page 1406
*
(2/st)
JH1160 Series Soft-Close Hardware
*Use with new version 111 track only*
2 sets per door required for dual function
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 1375 Prices subject to change without notice.
McMurray.com
JH1160
Option Available
