Charles McMurray Co. 2023 Catalog

1376 / 1645

JH134F Series Sliding/Bypass Door Hardware
Aluminum Fascia Track
Door Stop
Bulk Pack - Track & hardware sold separately
Track
Item No. Length Box List Ea.
List Ea.
Full Box
60" 10 $71.10 $60.44
72" 10 $84.68 $71.98
96" 5 $114.98 $97.74
120" 5 $149.80 $126.94
144" 10 $178.14 $150.96
* Must ship LTL
2-Door Hardware Sets
Set No. Description Box List Set
List Set
Full Box
For 125 lb. doors 25 $46.46 $39.38
For 200 lb. doors 25 $85.56 $80.42
JH30US15
2-1/8" Nickel Pull
Adjustable Bypass
Door Guide
Components
NOTES:
For sliding/bypass components & accessories see pages 1382-1389.
For flush pulls see pages 1328.
For soft-close hardware see page 1368.
Installation instructions and videos are available at
under the Resources tab.
Maximum Weight with JH1120 hangers: 125 lbs. per door
Maximum Weight with JH1125 hangers: 200 lbs. per door
Door Thickness: 1-3/4"
• Aluminum single extruded twin box rail fascia track can be cut-down to
accommodate narrower doors; mill finish
• Convex rails provide one-point contact for wheels to ride on; dirt traps on both sides
allow hanger wheel to be dust-free
• Tricycle hanger design gives even weight distribution
to track rails; will not bind
• Commercial grade
top hung sliding
door hardware
Wrench
200 lb. Hanger - Ball-Bearing
Item No. Description Box List Ea.
Hanger f/125 lb. (pair) 50 pr
Hanger f/200 lb. (bulk) 50 ea $16.22
Hanger f/200 lb. (pair) 50 pr $31.98
Wrench 100 ea $1.10
Door Guide 25 ea $4.38
Door Stop 50 ea $2.92
125 lb. Set Includes 200 lb. Set Includes
2 pr JH1120 hangers 2 pr JH1125 hangers
2 ea JH30US15 2-1/8" flush pull 2 ea JH30US15 2-1/8" flush pull
1 ea JH2134 door guide 1 ea JH2134 door guide
1 ea JH2155 door stop 1 ea JH2155 door stop
1 ea wrench 1 ea wrench
Mounting screws Mounting screws
JH1120PLB2
125 lb. Hanger
Wheel: 1" dia.
Plate: 3/4"x2-1/4"
Wheel: 1" dia.
Plate: 3/4"x2-1/4"
min 1-3/4"max 2-1/4"
3/8"
2-3/16"
door height +2-3/8"
2-3/16"
4"
*
JH1060
Option Available
Item No. Series List Ea. List Ea. 5
Soft-close/soft-open (for dual function order 2 sets)
100, 134F, 138F $77.34 $72.40
Retrofit soft-close/soft-open (single direction only)
100, 134F, 138F $104.08 $86.06
JH1060 Series Soft-Close Hardware
2 sets per door required for dual function
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 1376 Prices subject to change without notice.
McMurray.com
