Charles McMurray Co. 2023 Catalog

1374 / 1645

NOTES:
For sliding/bypass components & accessories see pages 1382-1389.
For flush pulls see pages 1328.
For soft-close hardware see page 1368.
Installation instructions are available at
under the Resources tab.
This track can also be used for:
Pocket Doors............ page 1392
Folding Doors........... page 1406
00 Sliding/Bypass Door Hardware
Maximum Weight with JH1120 hangers: 125 lbs. per door
Maximum Weight with JH1125 hangers: 200 lbs. per door
Minimum Door Thickness: 1"
Bulk Pack - Track & hardware sold separately
Track
Item No. Length Box List Ea.
List Ea.
Full Box
48" 25 $26.08 $21.66
60" 25 $32.04 $26.60
72" 25 $37.32 $31.10
96" 10 $52.46 $43.72
120" 10 $77.14 $67.70
144" 10 $92.28 $81.20
192" 10 $129.40 $113.56
* Must ship LTL
2-Door Hardware Sets
Set No. Description Box List Set
List Set
Full Box
For 125 lb. doors 25 $44.64 $37.94
For 200 lb. doors 25 $85.64 $71.88
Hardware
Item No. Description Box List
Guide-centered (white) 100ea $1.38
Soft-close/Soft-open Hardware 5ea $77.34
Soft-close Hardware 5ea $104.08
Guide-offset (white) 100ea $1.04
Hanger f/125 lb. (pair) 50pr
Hanger, Ball-Bearing (pair) 50pr $31.98
Hanger, Ball-Bearing (bulk-full box) 50ea $16.22
Adjustment Wrench 100ea $1.10
Guide-steel reinforced 25ea $5.02
Single Post Door Guide 25ea $5.26
Multi-Door Pull Catch (2/st) 10st $13.84
Door Stop 50ea $2.92
Components
JH11
Offset Guide
JH10
Centered Guide
JH2054PLBG
Multi-Door Pull Catch
JH1125PLB2
Up to 200 lb.
JH2155
Door Stop
2"
1.242"
1.787"
JH2031 Single Post
Heavy-Duty Door
Guide (Zinc w/White)
JH2030 Single Post
Door Guide
(Zinc w/White)
Plate: 2-1/4"
x 3/4"
Plate: 2-1/4"
x 3/4"
• Heavy-duty extruded aluminum independent box rail
• Top hung hardware; all door weight is suspended from the track
• Residential and light commercial rated
Components Needed for 2-Door, 4-Door
2-Door 4-Door
JH100 track 2 ea 2 ea
JH1125 or JH1120 Hanger 2 pr 4 pr
JH11 offset door guide 2 ea 4 ea
JH10 centered door guide 1 ea 2 ea
JH2155 door stop 1 ea 2 ea
JH1712 adjustment wrench 1 ea 1 ea
Flush pulls 2 ea 4 ea
Wrench
Wheel: 1" dia.
Plate: 3/4"x2-1/4"
JH1060
Option Available
JH1120PLB2
125 lb. Hanger
Wheel: 1" dia.
Plate: 3/4"x2-1/4"
*
(2/st)
JH1060 Series Soft-Close Hardware
2 sets per door required for dual function
