Charles McMurray Co. 2023 Catalog

Hinge 101 103 203 204 208 212 216 218

3/8"

1/2" 1/2"

1/2"

5/8"

3/4"

1-1/8"

B 19/64" 3/8" 23/64" 23/64"

29/64"

35/64"

47/64"

7/8"

C 1-11/16" 1-1/2" 1-3/4" 2-3/8"

2-3/4"

3-3/4"

4-5/8"

D 7/64" 1/8" 7/64" 7/64"

9/64"

11/64"

15/64"

3/8"

3/32" 1/8" 1/8"

1/8"

5/32"

3/16"

1/4"

7/8" 11/16" 3/4" 1-1/4" 1-11/32"

2-1/16"

2 19/32" 2-15/32"

G 1/32" 1/32" 1/32" 1/32"

3/64"

1/16"

H 29/64" 19/32" 23/32" 23/32"

29/32"

1-5/64"

1-15/32" 1-41/64"

7/32" 7/32" 3/16"

1/4"

9/32"

3/8"

15/32"

13/32"

Min. Wood

Thickness 1/2"

3/4" 3/4"

3/4"

1-1/8"

1-3/8"

1-3/4"

Screw

Sizes

#5x3/4" #6x1 #6x1 #7x1-1/4 #8x1-1/4" #10x1-1/4" #14x1-1/2" #10x1-1/2"

Invisible Hinges

For usewithwood ormetal doors. Use for customfurniture,

cabinetry, displays. . . wherever a smooth, flushappearance

is important. Ideal for mirrored or appliquéd doors and

panels, pass doors, electronic cabinets, communication

and computer room doors and security. Templates are

available on special order.

See following page to determine type and number

of hinges per application.

Heavy-Duty Applications

Medium-Duty Applications

Light-Duty Applications

1 pair per card with wood screws.

Sold per pair.

1 each per box with wood screws.

Sold per each.

Item No.

Height (C)

Finish

List Pr.

SS101US4

1-11/16"

Satin Brass

$59.86

SS103US4

1-1/2"

Satin Brass

$56.26

SS103US26D

1-1/2"

Satin Chrome $56.26

SS203US4

1-3/4"

Satin Brass

$66.16

SS203US26D

1-3/4"

Satin Chrome $66.16

SS204US4

2-3/8"

Satin Brass

$73.66

SS204US26D

2-3/8"

Satin Chrome $73.66

1 each per box with wood screws.

Sold per each.

Item No.

Height (C)

Finish List Ea.

SS216US26D-EACH

4-5/8" Satin Chrome $133.00

SS218US26D-EACH

4-5/8" Satin Chrome $137.60

Item No.

Height (C)

Finish List Ea.

SS208US26D-EACH

2-3/4"

Satin Chrome $45.36

SS212US4-EACH

3-3/4"

Satin Brass $85.84

SS212US26D-EACH

3-3/4"

Satin Chrome $85.84

Hinge Measurements

SS101US4 SS103US4 SS203US4 SS204US4 SS208US26D-EACH SS212US4-EACH SS218US26D-EACH SS103US26D SS203US26D SS204US26D
