HES3D-90 Series
3-Way Adjustable Concealed Hinges
• 3-way adjustment allows vertical, horizontal, and
depth adjustment after hinge installation
• Covers hide screw heads for a clean appearance
• Hinge leaves separate for easy installation and adjustment
• Min. Door Thickness: 15/16"
• Max. Door Size: 59-1/16"H x 23-5/8"W
• Max. Door Weight: 26 lbs./2 pcs., 35 lbs./3 pcs.
• Matte black or dull nickel finish
• 3-9/16"H x 1-13/16"W
2 each per box with steel flat head screws. Sold per each.
Item No. Finish List Ea.
List Ea.
2
Black $121.88 $102.64
Dull Nickel $121.88 $102.64 Dull Nickel (DN)
Matte Black (BL)
Bore Dimensions
