Technical data
Size 66 x 27 x 9.7 mm
Cutter Ø 100.4 x 7 x 22 mm
Installation Tolerance Longitudinal ± 1 mm, Radial ± 1 mm
Sold per box.
Item No. Box
Retail
Price
80 $85.00
300 $295.00
Pre-Load Clips
300 $65.00
TENSO P Self-Clamping Connectors for Gluing
Preload clip
The individual pre-loading of the
connectors considerably reduces the
amount of force needed when
connecting the workpieces.
Preload clip
(actual color is
black)
One insertion tool is
included with each
box of clips
TENSO P-10 - For Panels from 12 mm
Technical data
Size 52 x 19 x 9.7 mm
Cutter Ø 100.4 x 7 x 22 mm
Installation Tolerance Longitudinal ± 1 mm, Radial ± 1 mm
Sold per box. Includes preload clip.
Item No. Box Retail Price
80 $105.00
300 $350.00
TENSO P-14 - For Panels from 15 mm
• For use with Zeta P2 Biscuit Joiner or CNC machinery
• Work pieces are automatically in the correct angle
• Stackable for transport, despite integrated connector
• The option of pre-loading the connector prior to glue application
enables use for all angles and miters
• Made of fiberglass reinforced plastic
• 45° miters from a panel thickness of 19 mm
• 90° connections for a panel thickness from 15 mm
• Center panel connections from a panel thickness
of 19 mm
• 45° miters from a panel thickness of 15 mm
• 90° connections for a panel thickness from 12 mm
• Center panel connections from a panel thickness
of 16 mm
• Small opening 6 mm
• Short assembly time on site
• Versatility for all angles
• Detachable or glued construction
• Made of fiberglass reinforced plastic with zinc die-cast lever
Technical data
Size 64 x 27 x 9.7 mm
Cutter Ø 100.4 x 7 x 22 mm
Installation Tolerance Longitudinal ± 1 mm, Radial ± 1 mm
Tensile Strength MDF Particle Board Beech
200 lbs. 180 lbs. 220 lbs.
Sold per box.
Item No. Box Retail Price
80 $145.00
300 $510.00
1,000 $1,500.00
CLAMEX P-14 Detachable Connectors
For Panels from 16 mm
CLAMEX P-14 Flexus
With Flexible Positioning Pins
For Panels from 13 mm
• For material as thin as 13 mm (1/2")
• Fast tool-free installation for surface or corner joints
• Stackable for transport with connectors pre-installed
Technical data
Size 64 x 13.5 x 9.7 mm
Cutter Ø 100.4 x 7 x 22 mm
Installation Tolerance Longitudinal ± 0 mm, Radial ± 1 mm
Tensile Strength MDF Particle Board Beech
158 lbs. 132 lbs. 178 lbs.
Sold per box.
Item No. Box Retail Price
80 $145.00
300 $510.00
Flexible positioning pins in place of the rigid torsion tabs found
on the standard Clamex. This allows the workpiece components
to be slid and 'snapped' into place since the tabs retract until
they find their mating half. Packaged with a 14mm size male
half and a 10mm Medius female half, but like any other Clamex
connector it is interchangeable with the female halves of the
Clamex P-14 and P-10 as well.
Retail Prices shown are Colonial Saw retail prices.
Discounts not available on Colonial Saw retail prices.
