Item No.

Description

List Ea.

PC883356

3/8" Pocket Cutting Bit

$227.32

Replacement Bits For

PC552 Production Pocket Cutter

• 7.0 Amps, 120 VAC (10,000 rpm)

• Includes 4" diameter blade for standard biscuit cutting

• Precise micro-height adjustment knob

• Height scale accurate at any angle

• 7-position rotating depth stop for FF, #0, #10, #20, Simplex,

Duplex and Max (#6) biscuits

• Lock-on trigger

• Spindle lock for single wrench bit changes

• Bale handle attached to fence for greater stability and control

Includes: plate joiner, 4" blade (#5558), centering plate

(#888776), dust bag (#883175), chip deflector (#886490),

allen wrench (#891869), carrying case and operating manual.

Plate Joiner Kit

8mm x 40mm (Wood thickness 5/8"+). For use with

LDE900/910BP & 900BM.

Item No.

Box

List Ea.

List Ea.

Full Box

LD8002-40-R5

2000

$0.42

$0.36

LD8002 Spring Pin

Barbed Channel Lock Removable Joints

Requires CNC routing capability and edge boring machine.

Item No.

Material

Box

List Ea.

LDE900BP

Nylon

2000

$1.20

LDE900BM

Zinc Aluminum 500

$1.88

LDE3259BM

Zinc Aluminum 1000

$1.18

Routing Instructions

Plunge cut: Z: -4.5 Slot Cut: X: 0 to 34

Plunge cut: Z: -9.0 Key Slot: X: -30 to 34

(Allowable depth range: -9.0 to -9.3)

Route

RED

path first, then route

BLUE

path.

LDE900BP

LDE900BM LDE3259BM

• Pull force: 120-160 lbs.

• Sheer force:

LDE900BP 100+ lbs.

LDE900BM

500+ lbs.

• Drilling: 8 mm with 32 mm

spacing

• For 5/8"-3/4" thick material

• Pull force: 70+ lbs.

• Sheer force: over 250 lbs.

• Drilling: 5 mm with 32 mm

spacing

• For 1/2" thick material

04/24

02/23

Router Bits

100% carbide. Cutting length: 11mm, overall length: 76.2mm

Item No.

Routs

# of

Flutes Dia. Shank List Ea.

LDE1000B EClips/T-Slots 2 3/8" 3/8" $210.60

Item No

Price Ea.

PC557
