• 3 Watts per foot Luniform output for continuous illumination, light temperature 3000K (warm) or 4800K (cool)
• 16.4' roll, cuttable every 1"
• Linkable with B2B connectors or linking cords, no soldering required
• 79" starter cords are molded on each end for easy installation
• Recess or surface mount with u-clips indoor, outdoor, damp and
wet locations, when used with factory-installed inputs
Flexible Lighting (16.4' Roll)
Item No. Light Color List Ea. List Ea. 2
Warm 3000K $489.64 $414.96
Cool 4800K $489.64 $414.96
Warm 3000K $518.34 $439.26
Cool 4800K $518.34 $439.26
Power Supply (transformers)
Item No. Description List Ea.
L-DC-ELT15WP-CON 15W 12VDC Wall Mount* $70.24
L-DC-SLELT60-1 60W 12VDC Dimmable* $175.66
Neoloop works with all Tresco 12VDC power supplies.
See pg. 556 for more options/specifications.
Neoloop LED Flexible Silicone Lighting System
Accessories
Item No. Type Length List Ea.
List Ea.
10
Side-Emitting
Starter Cord 79" $60.34 $38.86
Link Cord 24" $79.20 $51.02
Link Cord 48" $83.72 $53.92
BTB Connector 1" $29.50 $19.00
End Cap 1/2" $1.74 $1.38
Top-Emitting
Starter Cord 79" $58.74 $37.84
Link Cord 24" $79.20 $51.02
Link Cord 48" $83.72 $53.92
BTB Connector 1" $28.44 $18.32
End Cap 1/4" $8.08 $6.42
See pages 551b for more sizes and specifications.
12V System-LED
Specifications Side-Emitting Top-Emitting
Wattage 3W/ft. 3W/ft.
Lumens 100/ft. 200/ft.
Efficacy (lm/W) 33.3 66.7
Input Voltage 12VDC 12VDC
Diode Life 50,000 Hours 50,000 Hours
Bend Radius/Axis 4" Horizontal 4" Vertical
Max. Per 60W
Power Supply 20' 20'
Mounting Recess/Surface Recess/Surface
Warranty 5 Year 5 Year
Certifications
Beam Angle 110° 145°
Top-Emitting (200 Lumens/ft.)
Illuminates from a curved top
Bends on a vertical axis
Uses: Under counter accents,
soffits or toe kick lighting
Side-Emitting (100 Lumens/ft.)
Illuminates from the side
Bends on a horizontal axis
Uses: Highlighting dark millwork,
outlining commercial logos & more
N1 N2
U-clips are sold in packs of 10.
Item No.
List Ea.
Pk.
List Ea.
10 Pks.
$28.18 $18.14
$32.70 $21.06
Surface mount w/u-clips
08/22
Neoloop Typical Setup
Power Supply
Mounting Block
(Included w/Power Supply)
Controller
(pg. 557-560 for options)
Top-Emitting Neoloop
Cuttable
every 1"
Tick marks on
mounting side of
light strip show
where to cut
Recess mount
Dado:(16mm)5/8"Wx(12mm)15/32"D
