Charles McMurray Co. 2021 Catalog

552b / 1590

Back-to-back connector
48", 10" or 2" Cord
Easily connect two
FlexTape sections,
no soldering required.
Optional Items
Item No. Description List Ea.
L-RGBCCT1-CREC Child Controller $228.86
L-WLD-CCT-WH Wireless Wall Dimmer $259.36
L-4P6O Output Adaptor Cord $66.44
L-TPE-BTB-CCT-1 Back-to-Back Connector $4.52
Jumper Cords
L-TPELNK120-CCT 48" Linking Cord $15.68
L-TPELNK25-CCT 10" Linking Cord $10.10
L-TPELNK5-CCT 2" Linking Cord $7.44
See page 560-560a for available accessories.
LIGHTING
800.533.0533 2021 1946 552b Prices subject to change without notice.
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
FlexTape 3W Per Foot
Peel & Stick CCT LED Lighting
Specifications
Wattage 3W/ft.
Lumens 345/ft.
Efficacy (lm/W) 115
Input Voltage 12VDC
Lamp Life 50,000 Hours
Max. Per 60W
Power Supply 20'
Max Continuous Run 16.4'
Mounting Surface
Warranty 5 Years
Certifications
Beam Angle 115°
05/22
Changing your light source’s color temperature is easy with White
Tunable (CCT - Correlated Color Temperature) FlexTape LED liginting.
Select between a warmer temperature that highlights natural wood
grains and earth tones or cool to highlight whites.
High output FlexTape has a low profile that can be used in many discreet
locations. Diodes are placed 19/64" apart for greater coverage and
illumination. Sold by the roll (16.4').
12V System-LED
CCT FlexTape Typical Setup
CCT FlexTape®
Universal Receiver
Power Supply
Mounting Block
(Included w/Power Supply)
Starter Cord
• Wide 115° angle of light
• White tunable from 2700K - 6500K
• Dimmable
• Can be cut at 1" increments
• Linkable with jumper cord
• Strong 3M™ adhesive backing
For product specs
& information,
visit: https:/ bit.
ly/3u4ttwJ
Required Items
Light Fixtures
Item No. Description List Ea.
L-FLXTPE-12CCT White Tunable FlexTape $139.72
Universal Receivers
Item No. Description List Ea.
L-RGBCCT1-PREC Parent Controller $253.10
Universal receivers allow for precision color tuning. Use parent
controller for the first run of lights, use child receiver for each
additional run of lights.
Starter Cords
Item No. Description List Ea.
L-TPEPKT-2M-CCT 79" Starter Cord $253.10
L-TPEPKT-2IN-CCT 2" Starter Cord $14.88
Power Supply (transformers - choose one)
Item No. Description List Ea.
18W 12VDC $106.74
60W 12VDC Dimmable $175.66
NOTES: For use with 12V 60W max power supply.
See pg. 556 for specifications and more options.
