Charles McMurray Co. 2021 Catalog

548 / 1590

Specifications
Wattage 4W/ft.
Lumens 216/ft.
Efficacy (lm/W) 54
Input Voltage 12VDC
Lamp Life 50,000 Hours
Max. Per 60W
Power Supply 15'
Max. Continuous Run 10'
Mounting Surface
Warranty 5 Year
Certifications
Beam Angle 120°
Optional Accessories
See pages 556-560 for accessories.
12V System-LED
Eurolinx Typical Setup
Power Supply
Mounting Block
(Included w/Power Supply)
Controller
(pg. 557-560 for options)
Eurolinx Linear LED
LIGHTING
800.533.0533 2021 1946 548 Prices subject to change without notice.
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
:
Required Items
Light Fixtures
Item No. Length Watts List Ea.
Cool White (5000K)
19-3/4" 7W $174.58
31-3/4" 11W $213.72
43-3/4" 15W $261.36
Warm White (3000K)
7-3/4" 3W $163.82
19-3/4" 7W $174.58
31-3/4" 11W $218.08
43-3/4" 15W $261.36
Power Supply (transformers - choose one)
Item No. Description List Ea.
15W 12VDC Wall Mount* $70.24
18W 12VDC* $106.74
60W 12VDC Dimmable* $175.66
60W 12VDC Dimmable** $269.14
NOTES: See page 556 for specifications.
*Dimmable on trailing edge (12V side), 6-port mounting block
and power cord included.
**Dimmable by standard LED wall dimmers, 6-port mounting
block included.
Optional Items
Linking Cords & Dimmer
Item No. Description List Ea.
10" Linking Cord $22.72
24" Linking Cord $26.76
72" Linking Cord $38.14
Inline Touch Dimmer 27W* $50.70
*Controls up to 6' of Eurolinx lights
Eurolinx LED Linear Light System
Lighting Strips, 4W per foot
• Directional beam-spreads based on orientation
• Linkable (back-to-back or link cord) up to 10'
• 79" starter cord, 2 u-clips and back-to-back connector are included
• Mounting clips with integrated magnets allow for metal surface
mounting as well as traditional screw-mounting
• Dimmable
Optional Inline Gradual Dimmer (max. load 27W)
L-EULNK Linking Cords
Two Beam Spreads:
Powered Left Side
Powered Right Side
Linkable (back-to-back or link cord) up to 10' continuous run.
(Back-to-back link included.)
Mounting clips with integratedmagnets allow for metal surface
mounting as well as traditional screw mounting (2 included)
Length
Length
