Charles McMurray Co. 2021 Catalog

544 / 1590

Required Items
Light Fixtures
Item No. Finish Bulb List Ea.
Black Warm (3000K) $137.40
Nickel Warm (3000K) $137.40
White Warm (3000K) $137.40
Black Cool (5000K) $137.40
Nickel Cool (5000K) $137.40
White Cool (5000K) $137.40
Power Supply (transformers - choose one)
Item No. Description List Ea.
15W 12VDC Wall Mount* $70.24
18W 12VDC* $106.74
60W 12VDC Dimmable* $175.66
60W 12VDC Dimmable** $269.14
NOTES: See page 556 for specifications.
*Dimmable on trailing edge (12V side), 6-port mounting block
and power cord included.
**Dimmable by standard LED wall dimmers, 6-port mounting
block included.
• Durable all-metal construction
• 120° beam spread
• Luniform output - no "dots"
• 79" starter cord, AMP® connector and surface
mount ring are included
• Dimmable
Specifications
Wattage 3W
Lumens 234
Efficacy (lm/W) 78
Input Voltage 12VDC
Lamp Life 50,000 Hours
Max. Per 60W
Power Supply 20 Fixtures
Max. Continuous Run N/A
Mounting Recess/Surface
Warranty 5 Year
Certifications
Beam Angle 120°
Power Pockit® 3W LED Lights
Optional Accessories
See pages 556-560 for accessories.
Option 1 (To control each light individually):
Up to six Controllers plugged into (1) Mounting Block
Option 2 (To control all lights at the same time) :
One Controller plugged in before the Mounting Block
2-1/2"
3/8"
thru-way for wire exit
Surface Mount
79"
2-1/4"
2-1/2"
1/4"
Recess Mount
12V System-LED
See pg. 1135 for hole saws
Power Pockit® 3W Typical Setup
Power Supply
Mounting Block
(Included w/Power Supply)
Controller
(pg. 557-560 for options)
Power Pockit® 3W
