Charles McMurray Co. 2021 Catalog

550 / 1590

Recess Profile
Square
11/16"w, 1/2"h
30° Angle
1-1/8"w
9/16"
11/32"
Recessed
7/8"w, 5/16"h
Infinex LED Aluminum Extrusion System
Infinex is the integrated LED aluminum extrusion system. Simply cut to desired length to create a custom-
ized LED fixture. Designed for easy DIY application. Tresco also offers prefabricated customer solutions.
See Rev•A•Shelf spec guide for complete specifications and additional items.
Extrusion Profiles
Mounting Options (vary by profile)
Clear Diffuser
Frosted Diffuser
Diffuser Options
Screw - for Angle or Square U-Clip - for Square
*With Endcap: Route a channel in wood
21/64" depth minimum x 3/4" width.
Without Endcap: Route a channel in wood
9/32" depth minimum x 3/4" width.
Grooved sides allow
the recessed profile
to pressure fit into
place.*
some items
starter cord
end cap magnet
U-Clip
extrusion
U-Clip
end cap magnet
diffuser
optional diode
blending film
FlexTape
Milk Diffuser
Flush
3/4"w, 7/16"h
For channels that go the entire width or height
of the casework. Comes with milk diffuser (unat-
tached). No end caps needed.
Route channel 7/16"D x 3/4"w.
Flush Mount
12V System-LED
LIGHTING
800.533.0533 2021 1946 550 Prices subject to change without notice.
