Charles McMurray Co. 2021 Catalog

487 / 1590

3-9/16"
1-1/2"
KV4400 Series
Full Extension, Low Profile (36 mm)
Side Mount - 65 lb. Rating
• Traditional and 32 mm hole patterns
• Face frame mounting hole
• Telescopic movement on precision steel ball-bearings
• Lever disconnect
• Direct access mounting and adjustment
• Flexible mounting tabs can be adjusted for slide space variances
• For drawers up to 24" wide
Bulk pack 10 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length List Pair
List Pair
10
List Pair
30
10" $24.96 $21.96 $20.72
12" $26.54 $23.36 $22.04
14" $26.04 $23.10 $21.86
16" $27.84 $24.68 $23.36
18" $29.44 $26.12 $24.72
20" $30.94 $27.44 $25.96
22" $32.12 $28.50 $26.96
Mounting Brackets
width
width minus 1" to 1.062"
1.125"
1"
1/2"
min.
KV8455FM Series
Soft-Close Drawer Slide
Full Extension +1" Over-Travel
Side Mount - 90 lb. Rating
• Soft-Close Module with Force Management™ Technology
• 1/2" Side Clearance, no set-up change from KV8400 or KV8450
• Traditional and 32 mm hole patterns allow for easy, flexible
installation on framed and frameless cabinetry
• Three ball-bearings per inch and polymer stop cushions aid
with smooth quiet operation of the slide
• Push-in lever disconnect allows for easy drawer removal
• Ball retainer latch and ramps allow for easy drawer insertion
• For drawers up to 24" wide
• Telescopic movement on ball-bearings
Clearance 1/2", plus 1/32" minus 0" each side
Height 1-13/16"
Bulk pack 10 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length List Pair
List Pair
10
16" $57.88 $48.58
18" $58.60 $49.18
20" $59.32 $49.78
22" $56.64 $48.00
24" $60.98 $51.18
28" $62.22 $52.22
1/2" min. width minus 1" to 1.062"
1-1/8"
1"
width
Mounting Brackets
8403
Rear
Bracket
8404 Front
Bracket
* Includes 2-8403 rear brackets, 2-8404 front brackets,
screws & installation sheet.
Screws
#8 x 7/16" coarse thread, trusshead, #2 phillips.
Sold per box.
Item No. Box List Box
1c $5.88
10c $38.60
Screws
#8 x 7/16" coarse thread, trusshead, #2 phillips.
Sold per box.
Item No. Box List Box
1c $5.88
10c $38.60
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
SLIDES
800.533.0533 2021 1946 487 Prices subject to change without notice.
Item No. Description Box List
List
Full Box
Rear Bracket 200pr $12.84pr $11.24pr
Front Bracket 10pr $11.36 $9.94
Front & Rear Set* 20st $15.46 $14.46
Item
No. Description Box List Pair
List Pair
10
List Pair
20
Rear Bracket 10pr $15.16 $13.26 $10.60
