Charles McMurray Co. 2021 Catalog

493 / 1590

KV8000 Series
Undermount Pantry Slide
Over-Travel, 130 lb. Rating
2-1/4"
1-35/64"
• Removable mounting brackets
• Hold-in detent
• Key-hole style mounting holes
• Telescopic movement on ball-bearings
• Full Extension +.83"
• Anochrome finish
Polybagged 1 pair per bag with screws. 5 pair per box. Price
is per pair.
Item No. Size List Pair
List Pair
5
16" $179.74 $150.86
18" $183.50 $154.00
20" $186.26 $156.32
22" $179.56 $152.18
26" $215.86 $179.20
Screws
#8 x 5/8", panhead phillips. Sold per hundred (c).
Item No. Description List c
List c
120
Coarse Thread $5.82 $4.44
3/4" + .03"
3"
KV8900 Series
Extra Heavy-Duty Full Extension
Up to 500 lbs. (based on application)
Side Mount
• Telescopic movement on ball-bearings
• Heavy-duty stops are designed to survive rough use
• Non-disconnect
• Non-handed for easy installation
Load Rating Chart (using 18" slide)
Drawer Width Load Rating
18" 500 lbs.
42" 400 lbs.
36" 300 lbs.
32" 100 lbs. flat load
_______________________________________
_______________________________________
_______________________________________
_______________________________________
Polybagged without screws. Price is per pair.
Item No. Length Box List Pair
List Pair
Full Box
16" 4 $223.86 $185.38
18" 4 $242.76 $201.04
20" 4 $257.14 $212.94
22" 3 $278.84 $230.90
24" 3 $306.56 $253.88
28" 3 $346.12 $286.62
30" 2 $373.10 $308.96
32" 2 $402.04 $332.94
34" 2 $429.66 $355.82
36" 2 $443.78 $367.50
Bulk pack without screws. Price is per pair.
Item No. Length Box List Pair
List Pair
2
40" 1 $508.86 $421.40
42" 1 $557.44 $461.62
48" 1 $709.06 $587.18
60" 1 $1,122.42 $929.50
NOTE: This slidemust never be used as
a pull-out step, platform or any other
application supporting human weight
as injury may result.
Recommended Fasteners
Use 1/4" or (M6 Euro) flat, hex, or panhead screw for
.26 (6.6 mm) cabinet member holes
Use 1/4" or (M6 Euro) hex or panhead screw for
.26 (6.6 mm) drawer member holes
Use #10 or (M5 Euro) flat, hex, or panhead screw for
.20 (5.2 mm) cabinet member holes
Use #10 or (M5 Euro) hex or panhead screw for
.20 (5.2 mm) drawer member holes
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
SLIDES
800.533.0533 2021 1946 493 Prices subject to change without notice.
