Charles McMurray Co. 2021 Catalog

486 / 1590

Bulk pack 10 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length List Pr.
List Pair
10
List Pair
30
12" $29.42 $26.32 $25.00
14" $30.00 $26.84 $25.50
16" $30.90 $27.66 $26.26
18" $31.84 $28.50 $27.06
20" $32.50 $29.14 $27.70
22" $34.18 $30.72 $29.22
24" $38.86 $34.78 $33.04
26" $40.78 $36.50 $34.66
28" $46.82 $41.90 $39.80
KV8405 Series
1" Over-Travel Box or File Drawer Slide
Side Mount - 100 lb. Rating
• 1" over-travel for full access to drawer contents
• Face frame mounting hole
• Telescopic action on ball-bearings
• Lever disconnect for easy drawer removal
• Non-handed design
• For drawers up to 24" wide
Mounting Brackets
8402
Rear
Bracket
8404 Front
Bracket
KV8407 Series
Side Mount w/Shelf Tabs
Full Extension - 100 lb. Rating
• Face frame mounting hole
• 32 mm hole pattern with direct access mounting
• Telescopic movement on ball-bearings
• Lever disconnect for easy drawer removal
• For drawers up to 24" wide
Bulk pack 10 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length List Pair
List Pair
10
16" $59.62 $50.04
18" $61.50 $51.60
20" $63.62 $53.40
22" $65.88 $55.28
Mounting Brackets
8402
Rear
Bracket
8404 Front
Bracket
slides are
Screws
#8 x 7/16" coarse thread, trusshead, #2 phillips.
Sold per box.
Item No. Box List Box
1c $5.88
10c $38.60
Screws
#8 x 7/16" coarse thread, trusshead, #2 phillips.
Sold per box.
Item No. Box List Box
1c $5.88
10c $38.60
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
SLIDES
800.533.0533 2021 1946 486 Prices subject to change without notice.
Item No. Description Box List Pair
List Pair
Full Box
Rear Bracket 200pr $15.58 $13.62
Front Bracket 10pr $11.36 $9.94
Item No. Description Box List Pair
List Pair
Full Box
Rear Bracket 200pr $15.58 $13.62
Front Bracket 10pr $11.36 $9.94
