Charles McMurray Co. 2021 Catalog

480 / 1590

Rear Mounting Bracket
TT100 Series
Full Extension
Side Mount - 100 lb. Capacity
Features:
• 32 mm & traditional hole patterns
• Face frame mounting hole
• Telescopic movement on steel ball-bearings
• Non-handed lever disconnect
• Positive stop bumper provides an anti-rebound feature
• 1/2" + 1/32" side clearance
• Height: 45 mm (1-49/64")
• Zinc finish
• Meets BHMA test standards
slides are
440 pair per box without screws. Sold per pair.
Item No. Length Travel List Pair
List Pair
10
List Pair
50
10" 250 (9.84") $17.10 $14.88 $13.96
12" 300 (11.81") $18.96 $16.48 $15.48
14" 350 (13.78") $20.90 $18.18 $17.06
16" 400 (15.75") $23.10 $20.08 $18.86
18" 450 (17.72") $22.80 $19.82 $18.62
20" 500 (19.69") $22.42 $19.72 $18.60
22" 550 (21.65") $22.72 $20.16 $19.08
24" 600 (23.62") $28.82 $26.98 $23.92
26" 650 (25.29") $30.72 $28.76 $25.52
28" 700 (27.56") $32.54 $30.46 $27.02
Mounting Brackets
Item No. List Pr.
List Pair
10
List Pair
200
$4.98 $4.62 $4.06
Screws
#8 x 7/16" coarse thread, trusshead, #2 phillips.
Sold per box.
Item No. Box List Box
1c $5.88
10c $38.60
