Charles McMurray Co. 2021 Catalog

1282a / 1590

TE240 TECTUS Hinges
• Used in door frames made out of hollow metal or wood in flush interior doors
• Maintenance-free slide bearings
• Suitable for left and right-hand applications
• 6-1/8"H x 2"W
Specifications
Door weight 132 lbs. (w/ 2 hinges)
Door thickness 25 mm (1")
Opening angle 180º
Router bit 16 mm (5/8")
Router guide 30 mm (1-3/16")
Adjustment
Height and Width ± 3 mm (1/8")
Depth ± 1.0 mm (1/16")
Item No Finish List Ea.
List Ea.
4
Black $339.84 $274.76
Satin Chrome $344.50 $278.54
F2 (Satin Nickel Look) $233.78 $204.56
Satin Chrome F2 Finish
(Satin Nickel Look)
Mounted to a wood door frame Mounted to a wood door jamb
together with a mounting plate
Mounted to a hollow metal frame
with a receiver element
Milling template for a wood
door frame
NOTE: Mounting plates and receiving
elements available by special order.
07/21
NOTE: For doors taller than 96" but under 39" wide,
or for doors wider than 39", install a third hinge 14"
below the centerline of the upper hinge.
