Charles McMurray Co. 2021 Catalog

1278 / 1590

Full mortise. Meets codes for hotels, motels, institutions and com-
mercial buildings. Boxed with screws. Sold per each.
Item No. Finish Size Box List Ea.
Satin Nickel 4" 3 $52.34
Satin Chrome 4" 3 $50.28
Satin Chrome 4-1/2" 3 $66.04
Matte Black 4" 3 $41.72
Matte Black 4-1/2" 3 $74.52
Hinge HingeSize
Max. Door
Weight
Spring
Hinges
Ball Bearing
Butt Hinges
For use on 1-3/4" door
1250 4" 60 lbs. 1 2
1251 85 lbs. 2 1
1250 4-1/2" 70 lbs. 1 2
Maximum door size:
For labeled doors 3' x 7', the maximum door size is based on the
limits set forth by NFPA Standard #80. Labeled Doors require ball-
bearing hinges.
For non-labeled doors over 7'6" in height, use an additional hinge
for each additional 30" of height or fraction thereof.
NOTES:
• For maximum versatility use all spring hinges or a
combination of springs hinges and ball-bearing hinges.
Do not use plain-bearing hinges.
• Do not use a spring hinge at the top position.
• Full spring tension may not be required on all hinges.
Commercial Grade 1/4" Radius
Single-Acting Spring Hinge
Full mortise. Meets codes for hotels, motels, institutions and com-
mercial buildings. Boxed with screws. Sold per each.
Item No. Finish Size Box List Ea.
Satin Chrome 4" 3 $58.78
Commercial Grade Square Corner
Single-Acting Spring Hinges
Hinge
Size
Number
of Holes
Gauge
of Metal
Machine
Screw
Wood
Screw
4" 8 .134 1/2x12-24 1-1/4" x 12 FH
4-1/2" 8 .134 1/2x12-24 1-1/4" x 12 FH
Corner Chisel
Use for squaring corners.
Item No. List Ea.
$51.06
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 2021 1946 1278 Prices subject to change without notice.
