Charles McMurray Co. 2023 Catalog

510a / 1645

02/24
Hawa Clipo 16 H Inslide
Sliding Bypass Cabinet Door System
for Wood Doors
Order hardware set, track and soft-close separately.
Set No. Description List Set
Hawa Clipo 16 H Inslide Hardware Set $169.34
Track: 2500 mm (98-7/16"), sold per each. Mounting hardware not included.
Item No. Description List Ea.
Single Running Upper Track $58.36
Double Running Upper Track $136.44
Lower Guide Rail $31.60
• Maximum door height: 1400 mm (55-1/8")
• Maximum door weight: 35 lbs.
• Maximum door width: 1000 mm (39-3/8")
• Door thickness: 16-19 mm (5/8" to 3/4")
• Self-closing clip-on system with height adjustment
• Hardware for (2) top-running bypass doors
• Screw-on or groove mounted aluminum track (order separately)
• Optional soft-close (order separately)
Soft-Close SC17 SC35
Damper
(Up to 17
lb. load
rating)
2
Trigger
w/end
stop
2 2
Damper
(Up to 35
lb. load
rating)
2
Hardware Set
4 Running gear,plastic
2 End stop, plastic
4 Running gearhousing, plastic
1 Door follower,plastic
2 Bottom guide,plastic
Mounting hardware included
Track
2500 mm (98-7/16")
single running,
glue-on, aluminum
2500 mm (98-7/16")
double running,
pre-drilled, aluminum
2500 mm (98-7/16")
lower guide (5/16"
groove), plastic
See next pg. for more specs
Upper track housing (press-fit)
Soft-Close: Sold per set. Order one set per door for soft-close/soft-open.
Mounting hardware included.
Set No. Description List Set
Up to 17 lb. load rating $86.62
Up to 35 lb. load rating $91.62
For further information
on Hawa Clipo 16 H IS
visit:
