SlideLine M Sliding Door System
Bottom Running
Silent System in closing, opening and colliding directions.
Inset Door Position
• 1-track, bottom running sliding door system
• Wood, glass or aluminium framed doors
• Shelf thicknesses 15, 16, 18, 19, 22, 25 mm
• 1-track or 2-track bottom-running sliding door system
• 2-door or 3-door application
• Runner and guide profile for screwing on or pressing in
Overlay Door Position
Fittings Set for Doors, with Silent System
(Soft-closing, Soft-opening and Soft-colliding)
Set contains all components
required for 1 wood door, or
1 55 mm aluminum profile
door.
Set No.
List Set
SL9156.338 $242.44
Set Includes
2
Running components with
Silent System
2 Guide components
2 Activators
2 End stops, top
2 Guide bushes
1 Silent System in colliding direction
1 1.5 mm hexagon socket spanner
Fixing screws for wood doors
• Door weight up to 66 lbs.
• Door height up to 2000 mm
• Door width from 450 - 1800 mm
• Door thickness: Inset 5/8" to 3/4",
Overlay 5/8" to 1"
• Wood, glass or aluminum framed doors
• +/- 2 mm height adjustment
2-Track Runner Profiles
• Two runner profiles must be fitted per 2-door or 3-door cabinet
• 2500 mm length aluminum, silver anodized
Item No.
Description
List Ea.
SL9227.183
With Holes (Screw-on)
$84.76
Fittings Set - Order one per door, Overlay or Inset
Order one set per door.
