Lapcon Adjustable Soft-Down Lid Stays
For Downward-Opening Lids
• For downward-opening flap door with piano, butt or drop hinges (not included)
• Designed to hold door in closed position
• Speed adjustment screw located on front for easy adjustment
• Torque Calculation:
Torque = Door Height × 1/2 × Door Weight
Per Piece: 19-60 lbs./inch
Per Pair: 38-120 lbs./inch)
• Steel with nickel finish
• Includes mounting bracket for wooden door and steel screws
Item No. Description Box List Ea.
List Ea.
Full Box
Left Hand 20 $49.46 $40.36
Right Hand 20 $49.46 $40.36
Face Frame Bracket - sold per each
Bracket 30 $11.92 $9.92
Drop-Lid Hinges (see pg 281 for details)
Item No. Finish Box List Ea. List Ea. 10
Black 50 $19.68 $16.34
Nickel 50 $17.78 $14.76
This drawing shows (right-hand side mounting).
(left-hand) is symmetrical.
NSDX-SZ mounting plate for
wooden door, screw-on type
(included)
Hinge Type A B C D
Drop-Hinge (SDH-001)* 97 91 107 11
Piano/Butt Hinge 90 99 115 11
* In case overlay 16mm.
(sold separately)
