Charles McMurray Co. 2023 Catalog

325 / 1645

• For top-opening lids with piano, butt or concealed hinges
• Opening angle 70° or 105°
• Holds door in fully opened position
• Speed adjustment screw located on front for easy adjustment
• Torque Calculation :
Torque = Door Height × 1/2 × Door Weight
Per Piece: 19-60 lbs./inch
Per Pair: 38-120 lbs./inch
Lapcon Adjustable Soft-Down Lid Stays
For Top-Opening Lids
Item No. Description Box List Ea. List Ea. 20
Left Hand 20 $49.46 $40.36
Right Hand 20 $49.46 $40.36
hinge not
included
Lapcon Adjustable Soft-Down Lid Stays
For Upward-Opening Lids
• For upward-opening doors with piano, butt or concealed hinges
• Opening angle 80°, 90° or 100°
• Holds door in fully opened position
• Speed adjustment screw located on front for easy adjustment
• Torque Calculation :
Torque = Door Height × 1/2 × Door Weight
Per Piece: 19-60 lbs./inch
Per Pair: 38-120 lbs./inch
Item No. Description Box List Ea. List Ea. 20
Left Hand 20 $49.46 $40.36
Right Hand 20 $49.46 $40.36
hinge not included
This drawing shows (right-hand sidemounting).
(left-hand) is symmetrical.
This drawing shows (right-hand sidemounting).
(left-hand) is symmetrical.
Note: "S" dimension is the overlay coverage for concealed hinge(s).
80° to 100°
