Charles McMurray Co. 2023 Catalog

1396b / 1645

Guides
(2/St, White)
POCKET DOOR ACCESSORIES
512080
passage end
jamb bracket All steel
split
studs
512085
512086
pocket
end jamb
brackets
07/24
Components
Item No. Description Box List Ea.
Hanger w/Ball Bearings (pair) 25pr $71.54
Hidden Door Guide (set) 10st $13.06
Bumper 100ea $0.90
Guides (2/st) 100st $1.16
Floor Bracket 1ea $3.16
Bumper
000PF Commercial Grade Heavy Duty Pocket Door Frames
(2" x 4" stud walls)
Packaged Sets Include
Header (factory assembled)
1 ea 200 Series track
1 ea 512080 passage end jamb bracket
1 ea 512086 pocket end jamb bracket
2 ea 020 ball-bearing door hangers
1 ea hidden door guide set
1 ea standard pocket door guide
1 ea bumper
4 ea All steel split stud lengths (6 ea in 4'0" sets)
2 ea split stud floor brackets (3 ea in 4'0" sets)
1 pk Mounting screws
Maximum Door Weight: 400 lbs. per door
Door Thickness: 1-3/8" to 1-3/4"
Minimum Wall Structure Thickness: 3-1/2"
NOTES:
For Johnson pocket door accessories see pages 1397-1403.
For Soft-Close hardware see page 1368.
Installation instructions are available at
under the Resources tab.
020 Hanger,
Ball-Bearing
1" Wheels
1-1/8" X 3-1/2"
• Designed to carry heavy solid core doors up to 400 lbs. each and
1-1/8" to 1-3/4" thick in standard 2 x 4 timber or 4" steel framed
stud walls when using 4" steel stud adapter kit
• Versatile frame can be adapted for use in non-standard wall
thicknesses, block masonry walls and can be cut-down to accept
any smaller door size
• Heavy gauge galvanized all steel split studs
• Heavy duty smooth rolling, height adjustable door hanger with
quick-release clip
• 4-wheel hangers with tripod rocker design ensure all wheels carry
weight equally
• Precision extruded I-beam track
• Jump-proof design prevents rollers from jumping track
• Includes hidden & standard door guide options
Packaged Sets
Set No. Door Size Rough Opening List Set
2'6" x 6'8" 61" x 86-3/4" $412.78
2'6" x 8'0" 61" x 102-3/4" $472.54
3'0" x 6'8" 73" x 86-3/4" $429.42
3'0" x 7'0" 73" x 90-3/4" $453.02
3'0" x 8'0" 73" x 102-3/4" $492.16
4'0" x 6'8" 97" x 86-3/4" $551.30
4'0" x 7'0" 97" x 90-3/4" $578.20
4'0" x 8'0" 97" x 102-3/4" $630.42
*Header is pre-marked to cut for narrower openings.
200 Series
I-beam
track
3-1/2" header cross
sections fits perfectly
in a 2 x 4 stud wall
for doors 1-1/8" to
1-3/4" thick.
Self-adjusting
floor bracket.
All steel split stud.
Standard &
hidden door
guide options.
JH2066
Option Available
JH2066 Series Soft-Close Hardware
*Use with new version 2020 hanger only*
2 sets per door required for dual function
Item No. Series List Ea. List Ea. 25
For soft-close & soft-open function
JH2066 200, 2000, 2060 $138.62 $112.62
finish floor
guide sub-floor
guide
cover
plate
Floor Bracket
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 1396b Prices subject to change without notice.
McMurray.com
