Charles McMurray Co. 2023 Catalog

1396a / 1645

512080
passage end
jamb bracket
All steel split
studs
511595
511562
pocket
end jamb
brackets
100 Series
box track
(2 included)
Wide 5-1/2" header
cross sections fits
perfectly in a 2 x
6 stud wall for (2)
doors 1-3/8" thick.
Self-adjusting
floor bracket.
All steel
split stud.
Finished floor &
sub-floor hidden
door guides.
07/24
POCKET DOOR ACCESSORIES
Components
Item No. Description Box List Ea.
Hanger w/Ball Bearings (pair) 50pr $31.98
Hanger w/Ball Bearings (bulk) 50ea $16.22
Track Stop 100ea $3.14
Bumper 100ea $0.90
Wrench 100ea $1.10
Side-Mount Door Guide 25ea $6.74
Door Guide Cover Plates 25ea $5.76
Floor Bracket 1ea $4.40
Side-Mount
Door Guide
Door Guide
Cover Plate
Track Stop Bumper
2PF Commercial Grade Bypass Pocket Door Frames
(2" x 6" stud walls)
Packaged Sets Include
Header (factory assembled)
2 ea 100 Series track
1 ea 512080 passage end jamb bracket
1 ea 511562 pocket end jamb bracket
4 ea ball-bearing door hangers
1 ea track stop
2 ea bumper
1 ea wrench
1 ea side-mount door guide
3 ea door guide cover plates
1 ea 2054 multi-door catch set
1 ea 2083 finished floor door guide
1 ea 2084 sub-floor door guide
4 ea All steel split stud lengths
2 ea split stud floor brackets
1 pk Mounting screws
Wrench
Maximum Door Weight: 200 lbs. per door
Door Thickness: 1-3/8"
Minimum Wall Structure Thickness: 5-1/2"
Packaged Sets
Set No. Door Size Rough Opening List Set
2'0" x 6'8" 72-7/8" x 85-3/4" $491.96
2'0" x 7'0" 72-7/8" x 89-3/4" $556.58
2'0" x 8'0" 72-7/8" x 101-3/4" $574.86
2'6" x 6'8" 78-7/8" x 85-3/4" $573.88
2'6" x 7'0" 78-7/8" x 89-3/4" $628.74
2'6" x 8'0" 78-7/8" x 101-3/4" $647.02
JH1060
Option Available
Floor Bracket
Hanger,
Ball-Bearing
1" Wheels
1" X 3"
1-3/8"
• Designedtocarrytwoheavysolidcorebypassingdoorsupto200 lbs.
each and 1-3/8" thick in standard 2 x 6 timber or 6" steel framed
stud walls when using 6" steel stud adapter kit
• Frame can be cut-down to accept smaller door size
• Ideal for applications where wall structure or obstacles do not
allow a deep pocket
• Heavy gauge galvanized all steel split studs
• Smooth rolling, height adjustable door hanger with
quick-release clip
• Tricycle hangers ensure all wheels carry weight equally
• Track has keyhole slots for easy removal without tearing out walls
• Extruded aluminum track box design prevents rollers from
jumping track
• Hidden door guide channel is routed in door bottom
JH1060 Series Soft-Close Hardware
2 sets per door required for dual function
NOTES:
For Johnson pocket door accessories see pages 1397-1403.
For Soft-Close hardware see page 1368.
Installation instructions are available at
under the Resources tab.
Item No. Series List Ea. List Ea. 5
For soft-close & soft-open function
100, 134F, 138F $77.34 $72.40
For soft-close or soft-open only
100, 134F, 138F $104.08 $86.06
