Charles McMurray Co. 2023 Catalog

1393 / 1645

0PF/HD Commercial Grade Pocket Door Frames
(2" x 4" stud walls)
Uprights for Taller Doors
Set includes 2 uprights & 1 floor bracket 511590 (for 1-3/8" door)
Set No. Door Height Stud Length List Set
96" 100-1/8" $93.86
3'6" & 4'0" doors require 3 upright sets; smaller doors require 2
sets per frame.
• Precisionextruded jump-proof box track
• Solid wood header section
• Self-adjusting floor anchors
• Minimum wall structure: 3-1/2"
• Heavy gauge all steel split studs
Self-Adjusting
Floor Brackets
Pocket accepts
1"-1-3/4" thick
doors, no adapter
required
100 Series
box track Components
NOTES:
For soft-close hardware see page 1368.
Converging door application requires JH1555PPK3 kit.
For Johnson pocket door accessories see pages 1397-1403.
eos are available at
under the Resources tab.
Wrench
Guides
(2/St, White)
Bumper
Hanger, Ball-Bearing
For 200 Lb., 1" Wheels
Hanger
For 125 Lb., 1" Wheels
Item No. Description Box List Ea.
Hanger (pair) 50pr $16.44
Hanger w/Ball Bearings (pair) 50pr $31.98
Hanger w/Ball Bearings (bulk) 50ea $16.22
Bumper 100ea $0.90
Guides (2/st) 100st $1.16
Wrench 100ea $1.10
Floor Bracket 1ea $3.16
1" X 3" 1" X 3"
Packaged Sets Include
Header (factory assembled)
1 ea 100 Series track
1 ea 512080 passage end jamb bracket
1 ea 511592 pocket end jamb bracket
2 ea split stud floor brackets (3 ea in 3'6" & 4'0" sets)
1 st guides 2/set
1 ea bumper
1 ea wrench
1 pk Mounting screws
125 lb. sets also include - hangers & studs
2 ea hangers
4 ea All-steel split stud lengths
200 lb. sets also include - hangers & studs
3'0" sets 3'6"/4'0" sets
2 ea 2 ea hangers
4 ea 6 ea All-steel split stud lengths
JH1575PPK3 adapter components
4 ea 6 ea Shims
2 ea 3 ea 511593 floor brackets for 1-3/4" door
512080
512085
511592
All steel
split studs
Packaged Sets
Set No. Door Size Rough Opening List Set
For doors up to 125 lbs.
JH152068PF 2'0" x 6'8" 49" x 84-1/2" $215.80
JH152468PF 2'4" x 6'8" 57" x 84-1/2" $221.62
JH152668PF* 2'6" x 6'8" 61" x 84-1/2" $225.24
JH152868PF 2'8" x 6'8" 65" x 84-1/2" $227.32
JH153068PF* 3'0" x 6'8" 73" x 84-1/2" $233.76
For 1-3/4" doors order JH1575PPK3 adapter kit separately.
For 200 lb. doors
2'0" x 8'0" 49" x 100-1/2" $278.04
JH152480HD 2'4" x 8'0" 57" x 100-1/2" $274.86
JH152680HD* 2'6" x 8'0" 61" x 100-1/2" $275.54
2'8" x 7'0" 65" x 88-1/2" $255.38
JH152880HD 2'8" x 8'0" 65" x 100-1/2" $278.44
JH153070HD 3'0" x 7'0" 73" x 88-1/2" $257.20
JH153080HD* 3'0" x 8'0" 73" x 100-1/2" $288.78
3'6" x 6'8" 85" x 84-1/2" $389.72
3'6" x 7'0" 85" x 88-1/2" $422.40
3'6" x 8'0" 85" x 100-1/2" $471.36
4'0" x 6'8" 97" x 84-12" $404.44
JH154070HD 4'0" x 7'0" 97" x 88-1/2" $426.18
JH154080HD 4'0" x 8'0" 97" x 100-1/2" $466.08
*Header is pre-marked to cut for narrower openings.
Maximum Weight with JH1120 hangers: 125 lbs. per door
Maximum Weight with JH1125 hangers: 200 lbs. per door
Minimum Door Thickness: 1"
512085
JH1060
Option Available
Item No. Series List Ea. List Ea. 5
For soft-close & soft-open function
100, 134F, 138F $77.34 $72.40
For soft-close or soft-open only
100, 134F, 138F $104.08 $86.06
Floor Bracket
07/24
JH1060 Series Soft-Close Hardware
2 sets per door required for dual function
Upright
