Cabinet Leveler System
Complete Kits
The Camar leveler system provides greater material yield, eliminates shimming,
andmakes floors accessible for storage, cleaning and extermination. The leveling
adjustment can easily be made from inside the cabinet as well as from below.
Cabinet sides no longer come in contact with the floor. 600 lb. load capacity
per leveler + socket - may vary depending on quality and thickness of cabinet
materials. Plastic feet are black.
Kit Installation
A 10mm hole through the bottom panel is required for fastening
the socket to the bottom of the cabinet. A 4mm wide x 8mm
deep cutout is required at the toe kick for the socket. Two types
of toe kick clips are available, the screw-mounted (as pictured)
or the groove-mounted, which requires a 1/8" kerf. The clip at-
taches to the toe kick and easily snaps on to the leg of the leveler.
Dimensions
Kit with Screw-On Toe Kick Clip
Reversible leg insert, offers 4" to 6-1/2" height
adjustment. See following page for detail.
Kit Component Dimensions
Polybagged Kit Includes:
No. Qty
345-10-02 4 - metal leg with insert & plastic foot,
4 to 6-1/2" height adjustment
830-H1-00 4 - metal sockets with hollow bolt
202-V1-T2 2 - toe-kick clips, 4-finger, screw-on
810-37-01 4 - cover caps - white
810-37-55 4 - cover caps - almond
4" to 6-1/2"
height
adjustment
Foot Covercap
24mm dia.
Socket
Item No. Box List Bag
List Bag
10
10 bags $77.54 $65.08
10mm drill bit-
Item No. List Ea.
$59.68
48mm 24mm
socket toe kick
foot
clip leg
bottom panel
side panel
®
54mm
60mm
