AXILO™ Plinth Adjusting Fitting System
• Serves as an arm extension
• Ergonomic installation for protection of the back
• Flexible, time-saving installation
• Easily adjusted by hand or with tool
• Large area of application from plinth height 2-1/16" to 8-21/32"
• Exact adjustment provided by the fine thread
Handle end has 1/4"
chuck and can be
turned by hand or
with a tool.
Mounting Plates - Screw-mounted black plastic.
Adjustment Feet - Black Plastic
• Plug fits into mounting plate
• Weight capacity: 330 lbs./ft.
• Adjustable at the side and from
above 3/8" to 13/16" using AXILO
adjusting tool
3-1/2" to 4-3/4"
4-1/2" to 5-11/16"
Plinth Holder
• For 3/4" panel thickness
• For mounting the plinth panel
• Plug fits into mounting plate
• Plastic
Plinth Clip
• Screw mounted
• For use from installation height H = 3-1/8"
• Plastic
Height Adjusting Tools
Adjustable Angle Height Tool
• For adjustment of AXILO 78 plinth system
• 1/4" chuck, includes 1/4" bit
• Adjustment angle height: 1-10°
Item No. Description Box List Ea.
List Ea.
20
Adjusting Tool-Adjustable 1 $186.94 ---
Mounting Plate 20 $3.00 $2.50
Corner Mounting Plate 20 $3.00 $2.50
Foot 3-1/2" to 4-3/4" 20 $5.22 $4.34
Foot 4-1/2" to 5-11/16" 20 $5.40 $4.50
Cabinet Foot Spacer 20 $2.56 $2.14
Adjusting Tool-Light 1 $37.76 ---
Plinth Holder for 3/4" 20 $2.94 $2.46
Plinth Clip 20 $2.18 $1.82
Corner Plate Rectangular Plate
Plinth height = H - 5-10 mm
(3/16" - 3/8")
Light Tool
• For height adjustment of the plinth foot
• Manual operation
• Fixed tool length
Cabinet Foot Spacer
• Plugs into bottom of existing foot to add height
• Can be stacked
• Black plastic
