Charles McMurray Co. 2021 Catalog

677 / 1590

• Pre-assembled bottom-mount set
• MOVENTO heavy-duty full-extension concealed
runners with BLUMOTION
• For 16 (5/8") drawer side thickness
• 19 (3/4") over-extension
• For face frame and panel applications
• Tool-free side-to-side, height and tilt adjustment
• Maximum 6 (1/4") cabinet bottom recess
• 135 lb. static load capacity
• Designed to be used with SERVO-DRIVE touch-to-
open feature (order separately)
• Overall cabinet depth 610 (24")
MOVENTO Waste/Recycle Set with SERVO-DRIVE Capability
For 21" Drawer Length
Set includes:
MOVENTO 21" heavy-duty runner set with pre-mounted
installation screws (qty 8)
Standard locking devices (1 pr BT51.7601) with instal-
lation screws
Installation template and instructions
Note: Drawer and bins not included
Item No.
Minimum
Opening
Drawer
Length List Set
15" W 533 (21") $165.12
18" W 533 (21") $165.12
Notes: Drawer and bins not included.
SERVO-DRIVE sold separately.
TIP-ON BLUMOTION sold separately.
See page 683 for Western Dovetail drawer boxes.
KV 35 quart bins (order separately) - 14-1/4"W x 9-3/16"D x 17-1/2"H
Item No. Color List Ea.
Silver $43.32
Set includes:
Drive unit (pre-attached)
Screw-on distance bumpers (qty 4) with installation screws (qty 8)
Double bottom bracket with installation screws (qty 2)
INSERTA cable connector
Adapter plate
Cable end protectors (qty 2)
Cable clips (qty 4)
110V plug-in power supply with six feet of universal cable
Installation template, instructions and user manual
SERVO-DRIVE for Waste/Recycle Set
NOTE: Power supply will operate up to two drive units in a double bottom bracket application. (Only 1 drive unit included in set.)
Item No. List Set
$618.12
Door opens automatically
with just a touch of the
cabinet front or a light
pull of the handle.
(1-5/8" required space behind drawer)
NOTES:
Cabinet bottom recess must be 6 (1/4") or less.
Interior roll-outs and roll-out shelf applications must be mounted to the
bottom of the cabinet or to a fixed shelf/panel.
Rear brackets and sockets cannot be used. Cabinet bottommust be flush
with top surface of bottom rail unless bottom-mount spacers are used.
Bulk slides only, for custom and wide
drawers (no crossrail). Includes standard
locking devices. NOTE: Pre-attached
1/4" spacers should not be removed.
Item No. List Pr.
$149.18
One set required per drawer
