Actro 5D Series Silent-Closing Slide
Full Extension, 88/154 lb. Capacity
• Silent System - integrated soft closing for quiet and gentle closure
• Tool-less intuitive adjustments:
height adjustment up to + 3 mm / - 1 mm
side adjustment up to ± 1.5 mm
radial adjustment up to ± 1.5 mm
tilt adjustment + 4 mm
• Optional: Depth adjustment up to ± 2 mm
• Optional: Push-to-Open Silent System
• Galvanized steel, suitable for rooms exposed to moisture
• Locking device for convenient slide-on installation (Must be ordered separately)
Order locking devices and screws separately.
Item
No.
Drawer
Length
(NL -10)
Minimum
Int. Depth
(NL +3) List Pair
List Pair
10
88 lb. capacity
340 (13-3/8") 353 (13-7/8") $81.46 $73.16
390 (15-3/8") 403 (15-7/8") $80.36 $72.20
440 (17-5/16") 453 (17-13/16") $81.20 $72.96
490 (19-5/16") 503 (19-13/16") $82.04 $73.68
540 (21-1/4") 553 (21-3/4") $86.88 $78.04
590 (23-1/4") 603 (23-3/4") $96.72 $86.88
154 lb. capacity
540 (21-1/4") 553 (21-3/4") $103.24 $92.76
590 (23-1/4") 603 (23-3/4") $113.08 $101.60
640 (25-1/4") 653 (25-11/16") $118.08 $0.00
690 (27-3/16") 703 (27-11/16") $127.92 $114.88
740 (29-3/16") 753 (29-5/8") $137.76 $123.72
Accessories
Item No. Description List Set List Set 50
Locking Devices - 2 per set $21.40 $20.18
Locking Device Depth Adjusters $10.54 $9.94
Slide Screws
Item No. Description Box Qty List Box
#7 x 3/4" Flathead Phillips 1c $9.86
#7 x 3/4" Flathead Phillips 5c $31.94
Locking Device
• Tool-less, intuitive side adjustment
up to ± 1.5 mm
• Zinc and plastic, gray
• Sold per pair
Depth Adjuster
• Tool-less installation
• Adjustment up to ± 2 mm
• For optional use with inset front panels
• Steel and plastic
• Includes 2 depth adjusters & 2 activators
• Cannot be used with Push-to-Open
10/21
Front Cross
Section
Drawer Back Preparation
Example: For 21" inside cabinet width and a 5/8" thick
drawer: 21" minus 3/8" = 20-5/8" drawer width
Formula for calculating outside drawer width
For drawer side thickness Deduct from inside cab. width
16 (5/8") 10 (3/8")
15 (19/32") 12 (1/2")
14 (9/16") 14 (9/16")
13 (1/2") 16 (5/8")
12 (15/32") 18 (11/16")
