Charles McMurray Co. 2021 Catalog

1177 / 1590

Slotting Cutter Assembly
3-Wing
Item No. B
C
Depth
of Cut
D
Large
Dia.
d
Shank
Dia.
L
Overall
Length List Ea.
1/8" 1/2" 1-7/8" 1/4" 2-3/8" $71.44
Chamfer Bit
2-Flute w/Ball-Bearing Guide
Item No.
D
Large
Dia.
B
Carbide
Height
C
Cutting
Length
d
Shank
Dia.
L
Overall
Length List Ea.
1-1/4" 1/2" 5/8" 1/4" 2" $68.84
Corner Rounding Bits
2-Flute w/Ball-Bearing Guide
Item No.
R
Radius
D
Large
Dia.
B
Carbide
Height
d
Shank
Dia.
L
Overall
Length List Ea.
1/8" 3/4" 3/8" 1/4" 2" $60.42
1/4" 1" 1/2" 1/4" 2" $69.12
3/8" 1-1/4" 5/8" 1/4" 2-3/16" $68.48
Rabbeting Bit
2-Flute w/Ball-Bearing Guide
Depth of Rabbet 3/8"
Item No.
D
Cutting
Dia.
B
Cutting
Height A
d
Shank
Dia.
L
Overall
Length List Ea.
1-1/4" 1/2" 3/8" 1/2" 2-3/8" $85.34
Tongue & Groove Assembly
2-Wing w/Ball-Bearing Guide
Tongue is cut as shown in assembly "A". For groove cut, reas-
semble the tool as shown in "B". Instructions included.
Item No.
D
Dia.
B
Cutting
Height
C
Depth
of Cut
d
Shank
Dia.
L
Overall
Length List Ea.
1-5/8" 3/4" 3/8" 1/2" 3" $185.72
d
L
B
C
D
d
1/4"
1/4"
1/4"
Used to make slots for T-moulding and weather stripping.
3 wings for better cut finish. Carbide tipped.
Item No.
D
Cutter
Dia.
B
Kerf
d1
Bore
Depth
of Cut List Ea.
1-7/8" 1/16" 5/16" 1/2" $45.00
1-7/8" 1/8" 5/16" 1/2" $50.64
1-7/8" 1/4" 5/16" 1/2" $53.10
3-Wing Slot Cutters
