Charles McMurray Co. 2021 Catalog

1183 / 1590

Features:
• Create splinter-free cuts, of any length, in any material, at any
angle
• Dust extraction means little to no cleanup
• Blades and variable speed adapt to the material and style of
cut in seconds
• Slip clutch gives you confidence when working with the
toughest or thickest of materials
• Dual splinterguards, on both sides of the blade, create
splinter-free cuts
• Spring-loaded riving knife (splitter) keeps the cut kerf open so
the material does not pinch the blade - reducing the chance of
kickback
• The slip clutch helps to minimize the risk of a kickback and
minimizes wear on the blade, gear case, and motor
• Blade changes are easier and safer using the FastFix system
which locks switch and arbor simultaneously for easy arbor
bolt removal
Includes
1 Standard Saw Blade HW W36
1 75" Guide Rail FS 1900
1 Splinterguard
1 Sight Window
1 Wrench
1 Plug-It Power Cord
1 T-Loc Systainer 5 (case)
Specifications
Arbor Diameter 1-3/32" (30mm)
Bevel Cuts 0° - 45°
Depth of Cut on Track 2-3/4" straight down, 2-1/8" at 45°
Depth of Cut w/o Track 2-15/16" straight down
Blade RPM 1,350 - 3,550
Blade Diameter 8-1/4"
Power Consumption 1,600 watts/13 amps 120 V AC
Weight 13.67 lbs.
No. Plunge Cut Track Saw
TS 75 EQ-F-Plus-FS USA
Features:
• Create splinter-free cuts, of any length, in any material, at any
angle
• Dust extraction means little to no cleanup
• Blades and variable speed adapt to the material and style of
cut in seconds
• Dual splinterguards, on both sides of the blade, create
splinter-free cuts
• Spring-loaded riving knife (splitter) keeps the cut kerf open so
the material does not pinch the blade - reducing the chance of
kickback
• Blade changes are easier and safer using the FastFix system
which locks switch and arbor simultaneously for easy arbor
bolt removal
• Compact, ergonomic and lightweight
Includes
1 Standard Saw Blade HW W42
1 55" Guide Rail FS 1400
1 Splinterguard
1 Sight Window
1 Wrench
1 Plug-It Power Cord
1 Systainer SYS3 M 337 (case)
Specifications
Arbor Diameter 1-3/32" (30mm)
Bevel Cuts -1° - 47°
Depth of Cut on Track 2-1/8" straight down, 1-11/16" at 45°
Blade RPM 2,000 - 5,200
Blade Diameter 6-1/4"
Power Consumption 1,200 watts/10 amps 120 V AC
Weight 9.92 lbs.
No. Plunge Cut Track Saw
TS 55 FEQ-F-Plus-FS USA
