Charles McMurray Co. 2021 Catalog

1176 / 1590

Solid Carbide
Single-Flute Panel Pilot Bits
Item No.
Type
of
Cut
D
Cutting
Dia.
B
Cutting
Length
d
Shank
Dia.
L
Overall
Length List Ea.
Flush 1/4" 1/4" 1/4" 1-1/2" $28.12
7° 1/4" 1/4" 1/4" 1-1/2" $29.10
Flush Trim Bits
2-Flute w/Ball-Bearing Guide
Item No.
D
Cutting
Dia.
B
Cutting
Length
d
Shank
Dia.
L
Overall
Length
Max.
RPMs List Ea.
1/4" 5/8" 1/4" 2-3/8" 28,000 $163.72
Solid carbide. Designed for trimming decorative
metal laminates. Cuts both metal laminates and
wood-based substrate material. Steel bearing
guide. Not for use on stainless steel.
Flush Trim "V" Groove Bits
2-Flute w/Ball-Bearing Guide
Item No.
D
Cutting
Dia.
B
Cutting
Length
d
Shank
Dia.
L
Overall
Length List Ea.
5/8" 1" 1/4" 2-5/8" $75.96
5/8" 1" 1/2" 3-1/4" $81.62
Item No.
a
Bevel
Degree
D
Cutting
Dia.
B
Carbide
Height
d
Shank
Dia.
L
Overall
Length List Ea.
15° 5/8" 1/4" 1/4" 2-3/32" $54.24
Bevel Trim Bit
2-Flute w/Ball-Bearing Guide
E-Z Change Flush Trim Bit
2-Flute w/Ball-Bearing Guide
Replaceable head, no resharpening. Carbide
tipped cutters aremounted on alloy steel arbors
with hex drive to eliminate slipping.
Item No.
D
Cutting
Dia.
B
Cutting
Length
d
Shank
Dia.
L
Overall
Length List Ea.
1/2" 1/2" 1/4" 1-31/32" $47.56
Replacement Cutters
3 per pack, sold per pack. $72.46
AM55170 replacement
cutters, 3 per pack.
