Charles McMurray Co. 2021 Catalog

1096 / 1590

Item No. Description List Ea.
3/8" Pocket Cutting Bit $212.44
9/64" Pilot Hole Bit $42.44
Replacement Bits For
PC552 Production Pocket Cutter
• 7.5 Amps, 120 VAC.
• Includes both 2" and 4" diameter blades for use with standard
and small face frame biscuits.
• Precision fence with micro-height adjustment.
• Fence tilts from 0° through 135° with positive adjustable stop
at 90°.
• Includes plate for centering stock to the 2" blade.
• Lock-on trigger.
• Spindle lock for easy blade changes.
• 1" O.D. dust port allows for vacuum hook-up.
Standard Equipment: Heavy-duty plastic carrying case, 2" (5559)
and 4" (5558) blades, adjustable fence, centering plate (888776),
allenwrench (891869), dust bag (883175), chipdeflector (886490)
and operating manual.
No. Plate Joiner Kit
Router Bits
8mm x 40mm (Wood thickness 5/8"+). For use with LDE900BP.
Item No. Box List Ea.
List Ea.
Full Box
LD8002-40 2000 $0.34 $0.30
LD8002 Spring Pin
Barbed Channel Lock Removable Joints
Requires CNC routing capability and edge boring machine
Item No. Material Box List Ea.
LDE900BP Nylon 2000 $1.20
Zinc Aluminum 1000 $1.12
Routing Instructions
Plunge cut: Z: -4.5 Slot Cut: X: 0 to 34
Plunge cut: Z: -9.0 Key Slot: X: -30 to 34
(Allowable depth range: -9.0 to -9.3)
Route RED path first, then route BLUE path.
100% carbide. Cutting length: 11mm, overall length: 76.2mm
Item No. Routs
# of
Flutes Dia. Shank List Ea.
LDE1000B EClips/T-Slots 2 3/8" 3/8" $210.60
LDE1000H LDE3259BM 2 1/4" 1/4" $256.38
100% carbide. Cutting length: 11mm, overall length: 65mm
Item No. Routs
# of
Flutes Dia. Shank List Ea.
2 1/4" 1/4" $210.60
LDSP Stopper Pin
8mm x 10mm, steel replacement spring
button for drawer slides.
Item No. Box List Ea.
LDSP 200 $0.36
10/22
LDE900BP
• Pull force: 120-160 lbs.
• Sheer force: over 100 lbs.
• Drilling: 8 mm with 32 mm
spacing
• Pull force: 70+ lbs.
• Sheer force: over 250 lbs.
• Drilling: 5 mm with 32 mm
spacing
11/22
11/22
DOOR
HARDWARE
TOOLS
FASTENERS
SHOP &FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
FASTENERS
