Technical data
Size 66 x 27 x 9.7 mm
Cutter Ø 100.4 x 7 x 22 mm
Installation Tolerance Longitudinal ± 1 mm, Radial ± 1 mm
Sold per box.
Item No. Box
Retail
Price
80 $77.00
300 $265.00
Pre-Load Clips
300 $57.00
TENSO P Self-Clamping Connectors for Gluing
Preload clip
The individual pre-loading of the
connectors considerably reduces the
amount of force needed when
connecting the workpieces.
Preload clip
(actual color is
black)
One insertion tool is
included with each
box of clips
CLAMEX P-10 Detachable Connectors
For Panels from 12 mm
Sold per box.
Item No. Box Retail Price
80 $135.00
300 $460.00
• Mitered connections in materials as thin as 15 mm (9/16")
• For use with Zeta P2 Biscuit Joiner or CNC machinery
• Made of fiberglass reinforced plastic with zinc die-cast lever
Technical data
Size 52 x 19 x 9.7 mm
Cutter Ø 100.4 x 7 x 22 mm
Installation Tolerance Longitudinal ± 0.5 mm, Radial ± 0.5 mm
Tensile Strength MDF Particle Board Beech
130 lbs. 130 lbs. 200 lbs.
TENSO P-10 - For Panels from 12 mm
Technical data
Size 52 x 19 x 9.7 mm
Cutter Ø 100.4 x 7 x 22 mm
Installation Tolerance Longitudinal ± 1 mm, Radial ± 1 mm
Sold per box. Includes preload clip.
Item No. Box Retail Price
80 $98.00
300 $310.00
TENSO P-14 - For Panels from 15 mm
• For use with Zeta P2 Biscuit Joiner or CNC machinery
• Work pieces are automatically in the correct angle
• Stackable for transport, despite integrated connector
• The option of pre-loading the connector prior to glue application
enables use for all angles and miters
• Made of fiberglass reinforced plastic
• 45° miters from a panel thickness of 19 mm
• 90° connections for a panel thickness from 15 mm
• Center panel connections from a panel thickness
of 19 mm
• 45° miters from a panel thickness of 15 mm
• 90° connections for a panel thickness from 12 mm
• Center panel connections from a panel thickness
of 16 mm
P-System Basic Assortment
Includes
80 Clamex P-14
80 Tenso P-14 w/preload clip
60 Clamex P-Medius 14/10
20 Bisco P-14
1 Tenso P-10/P-14 Preload Tool
Systainer T-Loc Box with Dividers
Item No. Retail Price
$400.00
For all angles. Fast and flexible. Hex 4 x 30 mm, length 290 mm.
Item No. List Ea.
$106.14
CLAMEX P Assembly Tool
Retail Prices shown are Colonial Saw retail prices.
Discounts not available on Colonial Saw retail prices.
