Charles McMurray Co. 2021 Catalog

1095 / 1590

• Small opening 6 mm
• Short assembly time on site
• Versatility for all angles
• Detachable or glued construction
• Made of fiberglass reinforced plastic with zinc die-cast lever
Technical data
Size 64 x 27 x 9.7 mm
Cutter Ø 100.4 x 7 x 22 mm
Installation Tolerance Longitudinal ± 1 mm, Radial ± 1 mm
Tensile Strength MDF Particle Board Beech
200 lbs. 180 lbs. 220 lbs.
Sold per box.
Item No. Box Retail Price
80 $135.00
300 $460.00
1,000 $1,365.00
CLAMEX P-14 Detachable Connectors
For Panels from 16 mm
• Cross ribs for easy insertion
• True to size in length and thickness
• Gridded surface for uniform glue spreading
• Flat ends so surplus glue remains inside the groove
• High breaking strength and finely ground edges
Wood Biscuits
Bulk, 1000 per box. Sold per box.
Item No. Description List Box
For 8 mm groove depth,
47x15x4 mm $136.74
For 10 mm groove depth,53x19x4 mm $127.82
For 12 mm groove depth,56x23x4 mm $120.00
• Clamping aid for work pieces which are difficult to clamp,
e.g. bulkheads, crown moulding etc.
• Use in combination with wooden biscuits
• Make of plastic, barbed cross ribs for grip
• Can be installed with any biscuit joiner
Sold per box.
Item No. Box List Box
LAMELLO-K20 250 $269.24
Plastic Biscuits
Technical data
Size 60 x 24 x 4.5 mm
Cutter Ø 100 x 4 x 22 mm
Transparent Plastic Biscuits
For Solid Surfaces
Technical data
Size 60 x 23 x 4 mm
Cutter Ø 100 x 4 x 22 mm
• For gluing solid-surface work pieces
• Transparent plastic to ensure it can't be seen in white solid
surfaces
• Can be glued with adhesive for solid surfaces
• Does not swell up
• Can be installed with any biscuit joiner
Sold per box.
Item No. Box List Box
250 $193.84
CLAMEX P-14 Flexus
With Flexible Positioning Pins
For Panels from 13 mm
• For material as thin as 13 mm (1/2")
• Fast tool-free installation for surface or corner joints
• Stackable for transport with connectors pre-installed
Technical data
Size 64 x 13.5 x 9.7 mm
Cutter Ø 100.4 x 7 x 22 mm
Installation Tolerance Longitudinal ± 0 mm, Radial ± 1 mm
Tensile Strength MDF Particle Board Beech
158 lbs. 132 lbs. 178 lbs.
Sold per box.
Item No. Box Retail Price
80 $135.00
300 $460.00
Flexible positioning pins in place of the rigid torsion tabs found
on the standard Clamex. This allows the workpiece components
to be slid and 'snapped' into place since the tabs retract until
they find their mating half. Packaged with a 14mm size male
half and a 10mm Medius female half, but like any other Clamex
connector it is interchangeable with the female halves of the
Clamex P-14 and P-10 as well.
Retail Prices shown are Colonial Saw retail prices.
Discounts not available on Colonial Saw retail prices.
