Charles McMurray Co. 2023 Catalog

921 / 1645

Rolling Ladder Hardware
Black, Oil-Rubbed Bronze, Satin Brass or Satin Nickel Hardware
Cherry, Maple or Red Oak Wood
Hammered antique brass available by special order.
Other woods available by special order.
Step One - Hardware Kit: Top Guide Style - Rollers or Rolling Hook?
Kit No. Description List Kit
Top Guide - Rollers
Without Brake
QG200.07 Standard - Oil-Rubbed Bronze $1,239.76
QG200.08 Standard - Black $1,239.76
QG220.08 Contemporary - Black $1,240.54
With Brake
Standard - Satin Brass $1,864.80
QG210.07 Standard - Oil-Rubbed Bronze $1,579.50
QG210.08 Standard - Black $1,579.50
Top Guide - Rolling Hook
Without Brake
QG500.07 Standard - Oil-Rubbed Bronze $1,240.54
QG500.08 Standard - Black $1,240.54
QG520.08 Contemporary - Black $1,240.54
With Brake
QG510.02 Standard - Satin Nickel $1,687.50
Standard - Satin Brass $1,901.46
QG510.07 Standard - Oil-Rubbed Bronze $1,579.50
QG510.08 Standard - Black $1,579.50
Contemporary - Black $1,579.50
1
Braking Wheel Locking Adjustment
Loosening braking mechanism too much will cause the
spring to fall out.
The amount of weight necessary to engage the braking
mechanism on the bottom wheel assembly is adjustable.
(The unit is preset for 70 lbs.)
Locate Allen drive screw at the
base of the wheel housing.
(Use7/32"Allenwrench for
adjustment.)
To decrease sensitivity (need
more weight to engage braking
mechanism), turn screw clockwise.
To increase sensitivity (need less
weight to engage braking mechanism),
turn screw counter-clockwise.
12/23
Available
finishes:
Black
Oil-Rubbed
Bronze
Satin Brass
Satin Nickel
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
FURNITURE HARDWARE
800.533.0533 921 Prices subject to change without notice.
McMurray.com
Top Guides
Step Support
Rolling
Hook
Kit includes 2 top guides, 2 bottom wheels, 7 ladder step
supports (for an 8' ladder), rail end stop thread tap, and
all fastening hardware.
Bottom Wheels w/non-marring wheels
(wheel 4" x 7/8")
Standard Contemporary
Rollers
500 lb.
Load Rating
