Charles McMurray Co. 2023 Catalog

Vertical Wallbed System

NOTE: You must build your own cabinet and door

Wall Bed Set

Set No.

Bed

Size

Load Rating

List Set

Dynamic Static

271.92.202

Dbl/Full

400 lbs. 1,000 lbs. $1,439.28

271.92.200 Queen 400 lbs. 1,000 lbs. $2,277.90

Double/Full Set Includes

Frame

Safety Brackets

2 Gas Pistons* (1600 Newton)

Mounting Hardware

Recommended Sizes & Weights

Bed Size Average

Front Panel

Mattress

Slat Kit or

Plywood Sheet

Total Lifting

Capacity

Dbl/Full

80 lbs.

55-80 lbs.

30-35 lbs.

165-195 lbs.

Queen 100 lbs.

65-85 lbs.

30-35 lbs.

195-220 lbs.

NOTE:

Wall bed will not operate properly unless the

above weight ranges are adhered to.

• Steel frame bed kit for vertical folding beds

• Available in Queen: 80" x 60" or Double/Full: 75" x 54",

for mattresses up to 10" thick (not included)

• Door brackets attach front panels to support bars

• Easy adjustment of front panels with included height

adjustment screws

• Optional comfort slat system available

• A variety of pistons available for different lifting powers

Optional Comfort Slat Kit

• Easy to install

• Flexible curved beechwood slats

• Increases comfort • Frame Material: Steel

Bed Size

Kit No.

List Kit

Double/Full

271.92.262

$352.86

Queen

271.92.260

$595.30

Optional Piston Cover Caps

Black steel cover caps conceal the

mounting plates and pistons.

Sold per pair.

Item No.

List Pair

271.92.250

$262.40

Item No.

Piston

Strength

Average

Front Panel

Mattress

Comfort Slat Kit or

Plywood Sheet

Combined Lifting

Capacity

List Each

271.92.268

1500N

75 lbs.

55-70 lbs.

30-35 lbs.

145-160 lbs.

$35.00

271.92.269*

1600N

80 lbs.

65-80 lbs.

30-35 lbs.

155-170 lbs.

$35.00

271.92.275

2200N

100 lbs.

95-115 lbs.

30-35 lbs.

225-250 lbs.

$44.91

*This piston is included in the Double/Full set. **Piston 271.92.272 included in the Queen set.

Optional Gas Pistons

For use if lighter or heavier mattress or front panels are being used. Sold per each.

Queen Set Includes

Frame

Safety Brackets

2 Gas Pistons** (1900 Newton)

Mounting Hardware

For installation instructions, visit: https://bit.ly/3AK6USV
