TANDEMBOX Waste/Recycle Set
D Back Height Drawer Series
150 lb. Load Rating
Gray w/Gray Containers
For a complete list of components see catalog pages 455-456.
A Width = inside cabinet width -75 (2-15/16")
Length = runner length -24 (15/16")
B Width = inside cabinet width -87 (3-7/16")
Height = 199 (7-13/16")
NOTE: Use 16 (5/8") material for bottom and back.
Calculating Dimensions
A
B
Minimum opening height = 495 mm (19-1/2") (container height + 50mm)
Minimum opening width = 15"
Minimum depth = actual runner length +3 mm (1/8")
Each kit contains:
1 pair Drawer Profiles
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each Inserta Front Fixing Brackets
1 pair Top Gallery Rails
1 each Cross Gallery Rod
4 each Single Gallery Connectors
2 each 35 Quart Containers
(KV-QT35PB-PT)gray (17-1/2"H)
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
Nominal Length: 22"
Actual Length: 21-5/8"
Set includes:
Drive unit (pre-attached)
Screw-on distance bumpers (qty 4) with installation screws (qty 8)
Double bottom bracket with installation screws (qty 2)
INSERTA cable connector
Adapter plate
Cable end protectors (qty 2)
Cable clips (qty 4)
110V plug-in power supply with six feet of universal cable
Installation template, instructions and user manual
SERVO-DRIVE for Waste/Recycle Set
NOTE: Power supply will operate up to two drive units in a double bottom bracket application. (Only 1 drive unit included in set.)
Set No.
List Set
BZ10NA30UGUS$618.12
Door opens automatically
with just a touch of the
cabinet front or a light
pull of the handle.
(1-5/8" required space behind drawer)
Kit No.
Finish List Kit
TB-TR22GGray $310.74
